 | English

1 609 92A 0XM | (5.12.14)

Bosch Power Tools



Danger area! Keep hands, fingers or
arms away from this area.

Observe the dimensions of
the saw blade. The hole di-
ameter must match the tool
spindle without play. Do
not use reducers or adapt-
ers.

When transporting the machine, hold it only at the locations
indicated.

Danger of crushes or contu-
sions! When transporting,
ensure that your fingers are
positioned around the
transport handle.

Indicates the individual
steps for adjusting the
handle.

Symbols and their meaning

Indicates the individual
steps for adjusting the
bevel angle.

Left column:

– Bevel angle range

Saw blade is inclined to the
left

Right column:

– Bevel angle range

Saw blade is inclined to
the right

– Bevel angle range

Complete tilting range of
the tool arm

Indicates the position of the
locking lever for locking the
tool arm and for adjusting
the bevel angle.

Do not dispose of power tools into house-
hold waste!

Only for EC countries:

According to the European Guideline
2012/19/EU for Waste Electrical and
Electronic Equipment and its implemen-
tation into national right, power tools that
are no longer usable must be collected
separately and disposed of in an environ-
mentally correct manner.

Symbols and their meaning

45°– 0

0 – 45°

45°+
