18

 | English

1 609 92A 1GK | (15.6.15)

Bosch Power Tools



Do not restart the cutting operation in the workpiece.
Let the wheel reach full speed and carefully re-enter
the cut.

The wheel may bind, walk up or kickback if the

power tool is restarted in the workpiece.



Support panels or any oversized workpiece to minimize
the risk of wheel pinching and kickback.

Large work-

pieces tend to sag under their own weight. Supports must
be placed under the workpiece near the line of cut and near
the edge of the workpiece on both sides of the wheel.



Use extra caution when making a “pocket cut” into ex-
isting walls or other blind areas.

The protruding wheel

may cut gas or water pipes, electrical wiring or objects that
can cause kickback.

Safety warnings specific for sanding operations



Do not use excessively oversized sanding disc paper.
Follow manufacturers recommendations, when select-
ing sanding paper.

Larger sanding paper extending be-

yond the sanding pad presents a laceration hazard and
may cause snagging, tearing of the disc, or kickback.

Safety warnings specific for wire brushing operations



Be aware that wire bristles are thrown by the brush
even during ordinary operation. Do not overstress the
wires by applying excessive load to the brush.

The wire

bristles can easily penetrate light clothing and/or skin.



If the use of a guard is recommended for wire brushing,
do not allow any interference of the wire wheel or
brush with the guard.

Wire wheel or brush may expand in

diameter due to work load and centrifugal forces.

Additional safety warnings

Wear safety goggles.



Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



Release the On/Off switch and set it to the off position
when the power supply is interrupted, e. g., in case of a
power failure or when the mains plug is pulled.

This pre-

vents uncontrolled restarting.



Do not touch grinding and cutting discs before they
have cooled down.

The discs can become very hot while

working.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Products sold in GB only:

 Your product is fitted with a

BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

Products sold in AUS and NZ only:

 Use a residual current

device (RCD) with a rated residual current of 30 mA or
less.

Product Description and Specifications

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for cutting, roughing and brushing of
metal and stone materials without the use of water.
For cutting with bonded abrasives, a special cutting guard
(accessory) must be used.
When cutting in stone, provide for sufficient dust extraction.
With approved sanding tools, the machine can be used for
sanding with sanding discs.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Spindle lock button

2

On/Off switch

3

Auxiliary handle (insulated gripping surface)

4

Grinder spindle

5

Protection guard for grinding

6

Locking screw for protection guard

7

Mounting flange with O-ring

8

Grinding wheel *

9

Clamping nut

10

Two-pin spanner for clamping nut *

11

Quick-clamping nut

*

12

Carbide grinding head *

13

Protection guard for cutting *

14

Cutting disc *

15

Protection guard for grinding cup *

16

Grinding cup *

17

Two-pin spanner, offset, for grinding cup *

18

Hand guard *

19

Spacer discs *

20

Rubber sanding plate *

21

Sanding sheet *

22

Round nut *

23

Cup brush *

24

Cutting guide with dust extraction protection guard *

25

Diamond cutting disc *

26

Handle (insulated gripping surface)

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
