Specifications

91

 En

English

AD

DITIONAL

INFO

RM

A

T

ION

AUDIO SECTION

• Minimum RMS Output Power for Front, Center, Surround,

Surround Back

[U.S.A. and Canada models]

1 kHz, 0.9% THD, 8

Ω

......................................................  90 W

[Other models]

1 kHz, 0.9% THD, 6

Ω

  ......................................................  90 W

• Maximum Power for Front, Center, Surround, Surround Back

(JEITA)
 [Asia, General, China, and Korea models]

1 kHz, 10% THD, 6

Ω

  .....................................................  115 W

• Dynamic Power

[U.S.A. and Canada models]

(IHF, 8/6/4/2

Ω)

  ............................................ 90/110/130/150 W

[Other models]

(IHF, 6/4/2

Ω

)  .................................................... 100/110/125 W

• Dynamic Headroom [U.S.A. and Canada models]

8

Ω

....................................................................................  0.18 dB

• Maximum Input Signal

CD, etc. Effect On, 1 kHz, 0.5% THD  ...................  2.0 V or more

• Frequency Response

CD, etc. to Front L/R  ............................. 10 Hz to 100 kHz, –3 dB

• Total Harmonic Distortion

[U.S.A. and Canada models]

(1 kHz, 50 W, Front L/R, 8

Ω )

 .............................  0.06% or less

[Other models]

(1 kHz, 50 W, Front L/R, 6

Ω )

 .............................  0.06% or less

• Signal to Noise Ratio (IHF-A Network)

CD (200 mV) to Front L/R, Effect Off  ................... 98 dB or more
CD (250 mV) to Front L/R, Effect Off  ................. 100 dB or more

• Residual Noise (IHF-A Network)

Front L/R  ...............................................................  150 µV or less

• Channel Separation (1 kHz/10 kHz)

CD, etc. (5.1 k

Ω

 shorted) to Front L/R

................................................................... 60 dB/45 dB or more

• Tone Control (Front L/R)

BASS Boost/Cut  ...................................................  ±10 dB/100 Hz
TREBLE Boost/Cut  ..............................................  ±10 dB/20 kHz

• Headphone Jack Rated Output/Impedance  ..............  400 mV/470

Ω

• Input Sensitivity/Input Impedance

CD, etc.  .................................................................  200 mV/47 k

Ω

MULTI CH INPUT ...............................................  200 mV/47 k

Ω

• Output Level/Output Impedance

AUDIO OUT (REC)  ............................................  200 mV/1.2 k

Ω

SUBWOOFER OUTPUT  ............................................ 4 V/1.2 k

Ω

• Filter Characteristics (fc=40/60/80/90/100/110/120/160/200 Hz)

H.P.F.

(FRONT SP, CENTER SP, SUR. L/R SP, SUR. B L/R SP:
SMALL/SML) ............................................................ 12 dB/oct.

L.P.F. (Subwoofer)  ......................................................... 24 dB/oct.

VIDEO SECTION

• Video Signal Type (Gray back)

[U.S.A., Canada, Korea and General models]  ....................  NTSC
[Other models]  .......................................................................  PAL

• Video Signal Type (Video Conversion)  .........................  NTSC/PAL

• Signal Level

Composite  .................................................................  1 Vp-p/75

Ω

S-video  ............................ 1 Vp-p/75

Ω

 (Y), 0.286 Vp-p/75

Ω

 (C)

Component ...................  1 Vp-p/75

Ω

 (Y), 0.7 Vp-p/75

Ω

 (P

B

/P

R

)

• Signal to Noise Ratio  ................................................  50 dB or more

• Maximum Input Level ...........................................  1.5 Vp-p or more

• Frequency Response (MONITOR OUT)

Component Signal  .................................... 5 Hz to 60 MHz, –3 dB

FM SECTION

• Tuning Range

[U.S.A. and Canada models]  ...........................  87.5 to 107.9 MHz
[Asia and General models]  ........ 87.5/87.50 to 108.0/108.00 MHz
[Other models]  ............................................  87.50 to 108.00 MHz

• 50 dB Quieting Sensitivity (IHF, 100% mod.)

Mono  ................................................................. 2.8 µV (20.2 dBf)

• Signal to Noise Ratio (IHF)

Mono/Stereo  ..............................................................  73 dB/70 dB

• Harmonic Distortion (1 kHz)

Mono/Stereo ................................................................  0.5%/0.5%

• Antenna Input (unbalanced)  .....................................................  75

Ω

AM SECTION

• Tuning Range

[U.S.A. and Canada models]  ..............................  530 to 1710 kHz
[Asia and General models]  .................  530/531 to 1710/1611 kHz
[Other models]  ...................................................  531 to 1611 kHz

GENERAL

• Power Supply

[U.S.A. and Canada models]  .............................  120 V AC, 60 Hz
[Europe and Russia models] ..............................  230 V AC, 50 Hz
[Australia model]  ..............................................  240 V AC, 50 Hz
[Korea model]  ...................................................  220 V AC, 60 Hz
[China model] ....................................................  220 V AC, 50 Hz
[Asia model]

...................................................... AC 220/230–240 V, 50/60 Hz

[General model]

.......................................  AC 110/120/220/230–240 V, 50/60 Hz

• Power Consumption

[U.S.A. and Canada models]  .................................  240 W/320 VA
[General model]  .................................................................  260 W
[Other models]  ...................................................................  240 W

• Standby Power Consumption  ......................................  0.8 W or less

• Maximum Power Consumption [Asia and General models only]

7ch, 10% THD  ...................................................................  490 W

• AC  Outlets

[Australia model]  .......................................  1 (100 W maximum)
[U.S.A. and Canada models] ............... 2 (Total 100 W maximum)
[Asia, General, China, Europe and Russia models]

............................................................ 2 (Total 50 W maximum)

• Dimensions (W x H x D) .................................  435 x 151 x 352 mm

(17-1/8” x 5-15/16” x 13-7/8”)

• Weight  .............................................................  9.0 kg (19 lbs 13 oz)

* Specifications are subject to change without notice.
