60

 En

SET MENU

Surround left/right speakers

  SUR. L/R SP

Choices: NONE,

SML

, LRG

When the surround speakers are large

Select “LRG” (large).

When the surround speakers are small

Select “SML” (small).

When you do not use the surround speakers

Select “NONE” (none). This unit is set to the Virtual
CINEMA DSP mode (see page 41).

Surround back left/right speakers

SUR.B L/R SP

Choices: NONE, SMLx1,

SMLx2

, LRGx1, LRGx2

When the surround back left and right
speakers are large

Select “LRGx2” (large x 2).

When the single surround back speaker is
large

Select “LRGx1” (large x 1).

When the surround back left and right
speakers are small

Select “SMLx2” (small x 2).

When the single surround back speaker is
small

Select “SMLx1” (small x 1).

When you do not use the surround back
speakers

Select “NONE” (none). The surround back channel
signals are directed to the surround left and right
speakers.

LFE Bass out

  LFE/BASS OUT

Use this feature to select the speakers that output the LFE
(low-frequency effect) and the low-frequency signals.
Choices: SWFR, FRNT,

BOTH

When a subwoofer is connected to this unit
and you want to get natural bass sound

Select “SWFR” (subwoofer). The LFE signals as well
as the low-frequency signals of other speakers set to
“SML” (or “SMALL”) are directed to the subwoofer.

When a subwoofer is connected to this unit
and you want to get rich bass sound

Select “BOTH” (both). The low-frequency signals of
any source are output from the subwoofer. The LFE
signals as well as the low-frequency signals of other
speakers set to “SML” (or “SMALL”) are directed to
the subwoofer. The low-frequency signals of the front
left and right channels are directed to the front left and
right speakers and the subwoofer regardless of the
“FRONT SP” setting (see page 59).

When you do not use a subwoofer

Select “FRNT” (front). The LFE signals, the low-
frequency signals of the front left and right channels,
and the low-frequency signals of other speakers set to
“SML” (or “SMALL”) are all directed to the front left
and right speakers regardless of the “FRONT SP”
setting (see page 59).

1 SOUND MENU

A)SPEAKER SET

SUR. L/R SP

NONE >SML

LRG

1 SOUND MENU

A)SPEAKER SET

SUR.B L/R SP

NONE

SMLx1 >SMLx2

1 SOUND MENU

A)SPEAKER SET

LFE/BASS OUT

SWFR FRNT>BOTH
