62

 En

SET MENU

■

Speaker distance

C)SP DISTANCE

Use this feature to manually adjust the distance of each
speaker and the delay applied to the respective channel.
Ideally, each speaker should be the same distance from the
main listening position. However, this is not possible in
most home situations. Thus, a certain amount of delay
must be applied to the sound from each speaker so that all
sounds will arrive at the listening position at the same
time.

Unit

  UNIT

Choices: meters

(m), feet (ft)

Initial setting:
[U.S.A. and Canada models]: feet (ft)
[Other models]: meters (m)
• Select “meters” to adjust speaker distances in meters.
• Select “feet” to adjust speaker distances in feet.

Speaker distances

Control range: 0.30 to 24.00 m (1.0 to 80.0 ft)
Control step: 0.10 m (0.5 ft)
Initial setting:
FRONT L/FRONT R/SWFR: 3.00 m (10.0 ft)
CENTER: 2.60 m (8.5 ft)
SUR. L/SUR. R/SB L/SB R: 2.40 m (8.0 ft)

• The available speaker channels differ depending on the setting

of the speakers.

• Instead of “SB L” and “SB R”, “SUR.B” is displayed if

“SUR.B L/R SP” is set to either “SMLx1” or “LRGx1” (see
page 60).

■

Center speaker equalizer

D)CENTER GEQ

Use this feature to adjust the built-in 5-frequency band
(100Hz, 300Hz, 1kHz, 3kHz and 10kHz) graphic
equalizer for the center channel so that the tonal quality of
the center speaker matches that of the front speakers. You
can make adjustments while listening to the currently
selected source component or a test tone.

Control range: –6.0 to +6.0 dB
Control step: 0.5 dB
Initial setting: 0 dB

Test tone

TEST

Use this feature to make adjustments for “CENTER GEQ”
while listening to a test tone.

Choices:

OFF

, ON

• Select “OFF” to stop test tones and output the currently

selected source component.

• Select “ON” to output test tones from the center and

front left speakers.

■

Low-frequency effect level

E)LFE LEVEL

Use this feature to adjust the output level of the LFE (low-
frequency effect) channel according to the capacity of
your subwoofer or headphones. The LFE channel carries
low-frequency special effects which are only added to
certain scenes. This setting is effective when the input
signal contains the LFE channel.
Control range: –20 to

0

 dB

Control step: 1 dB

Speaker

SPEAKER

Adjusts the speaker LFE level.

Headphone

HEADPHONE

Adjusts the headphone LFE level.

Depending on the settings of “LFE/BASS OUT” (see page 60),
some signals may not be output at the SUBWOOFER OUTPUT
jack.

SP DISTANCE

Adjusted speaker

FRONT L

Front left speaker

FRONT R

Front right speaker

CENTER

Center speaker

SWFR

Subwoofer

SUR. L

Surround left speaker

SUR. R

Surround right speaker

SB L

Surround back left speaker

SB R

Surround back right speaker

Notes

1 SOUND MENU

C)SP DISTANCE

1/2

.

UNIT

;;;;;;

meters

FRONT L

;;;;

3.00m

FRONT R

;;;;

3.00m

CENTER

;;;;;

2.60m

SWFR

;;;;;;;

3.00m

[ ]/[ ]:Up/Down

[ ]/[ ]:Adjust

p

p

p

[

1 SOUND MENU

C)SP DISTANCE

2/2

.

SUR. L

;;;;;

2.40m

SUR. R

;;;;;

2.40m

SB L

;;;;;;;

2.40m

SB R

;;;;;;;

2.40m

[ ]/[ ]:Up/Down

[ ]/[ ]:Adjust

p

p

p

[

Note

1 SOUND MENU

D)CENTER GEQ

TEST

>OFF

ON

.

100Hz

;;;;;;

0dB

300Hz

;;;;;;

0dB

1kHz

;;;;;;

0dB

3kHz

;;;;;;

0dB

10kHz

;;;;;;

0dB

[ ]/[ ]:Up/Down

p

p

p

[

[ ]/[ ]:Adjust

E)LFE LEVEL

.

SPEAKER

;;;;;;

0dB

HEADPHONE

;;;;

0dB

[ ]/[ ]:Up/Down

p

p

p

[

[ ]/[ ]:Adjust

1 SOUND MENU
