38

 En

Playback

You can combine a video image from a video source with
sound from an audio source. For example, you can enjoy
listening to classical music while viewing beautiful
scenery from the video source on the video monitor.

Press the input selector buttons (

4

) to select a

video source and then an audio source.

y

• You can also select “MULTI CH” as the audio source (see

page 36). Press

4

AMP

 and then press

D

MULTI CH IN

.

• Set the “BGV” parameter in the “MULTI CH SET” menu to the

desired setting to select the default background video input
source of the MULTI CH INPUT sources (see page 67).

You can display the format, sampling frequency, channel,
bit rate and flag data of the current input signal.

1

Press

4

AMP

 and then

K

MENU

.

The top “SET MENU” display appears in the OSD.

2

Press

7

n

 repeatedly to select “SIGNAL

INFO” and then press

7

ENTER

.

The audio information about the input source appears
in the OSD.

3

Press

7

l

 /

h

 to toggle between the audio

and video information displays.

4

Press

K

MENU

 again to exit from “SET

MENU”.

■

Audio information

“– – –” appears when this unit cannot display the corresponding
information.

■

Video information

“– – –” appears when this unit cannot display the corresponding
information.

HDMI error and message

Playing video sources in the
background of an audio source

Displaying the input source
information

Audio sources

Video sources

DVD

V-AUX

DTV/CBL

DVR

CD

MD/CD-R

TUNER

USB

DVD

SET MENU

TOP MENU

. ;

AUTO SETUP

;

MANUAL SETUP

.

A

;

SIGNAL INFO

[ ]/[ ]:Up/Down

[ENTER]:Enter

p

p

Information

Descriptions

FORMAT

Signal format. When this unit cannot detect a
digital signal, it automatically switches to
analog input.

SAMPLING

The number of samples per second taken from
a continuous signal to make a discrete signal.

CHANNEL

The number of source channels in the input
signal (front/surround/LFE). For example, a
multi-channel soundtrack with 3 front
channels, 2 surround channels and LFE, is
displayed as “3/2/0.1”.

BITRATE

The number of bits passing a given point per
second.

FLAG

Flag data encoded in DTS, Dolby Digital, or
PCM signals that cue this unit to automatically
switch decoders.

Note

Information

Descriptions

HDMI SIGNAL

Type of the source video signals and the
video signals output at the HDMI OUT
jack of this unit.

HDMI RES.

Resolution of the HDMI signals input or
output at the HDMI IN/OUT jacks of this
unit.

HDMI ERROR

(Only when error
is detected)

Error message for HDMI sources or
connected HDMI devices. See “HDMI
error and message” for details.

Note

Message

Cause

DEVICE OVER

The number of the connected HDMI
components is over the limit.

HDCP ERROR

HDCP authentication failed.

OUT OF RES.

The connected monitor is not compatible
with the resolution of the input video signal.
