63

 En

SET MENU

English

AD
V

ANCED

OPERA

T

ION

■

Dynamic range

F)DYNAMIC RANGE

Use this feature to select the amount of dynamic range
compression to be applied to your speakers or
headphones. This setting is effective only when this unit is
decoding Dolby Digital and DTS signals.

Speaker

SPEAKER

Adjusts the speaker compression.

Headphone

HEADPHONE

Adjusts the headphone compression.

Choices: MIN, STD,

MAX

• Select “MIN” (minimum) if you regularly listen at low

volume levels.

• Select “STD” (standard) for general use.
• Select “MAX” (maximum) to preserve the greatest

amount of dynamic range.

■

Audio settings

G)AUDIO SET

Use this feature to adjust the overall audio settings of this
unit.

Mute type

  MUTE TYPE

Use this feature to adjust how much the mute function
reduces the output volume (see page 37).
Choices:

FULL

, –20dB

• Select “FULL” to completely mute all the audio

output.

• Select “–20dB” to reduce the current volume by 20 dB.

Audio delay

  A.DELAY

Use this feature to delay the sound output and synchronize
it with the video image. This may be necessary when
using certain LCD monitors or projectors.
Control range:

0

 to 160 ms

Control step: 1 ms

Maximum volume

MAX VOL.

Use this feature to set the maximum volume level. This
feature is useful to avoid the unexpected loud sound by
mistake. For example, the original volume range is –80 dB
to +16 dB. However, when “MAX VOL.” is set to –5 dB,
the volume range becomes –80 dB to –5 dB.

Control range: –30 dB to +10 dB,

+16 dB

Control step: 5 dB

The “MAX VOL.” setting takes priority over the “INIT.VOL.”
setting. For example, if “INIT.VOL.” is set to –20 dB and “MAX
VOL.” is set to –30 dB, the volume level is automatically set to
–30 dB when you turn on the power of this unit next time.

Initial volume

INIT.VOL.

Use this feature to set the volume level when the power of
this unit is turned on.
Choices:

OFF

, MUTE, –80 dB to +16 dB

Control step: 1 dB

The “MAX VOL.” setting takes priority over the “INIT.VOL.”
setting.

F)DYNAMIC RANGE

.

SPEAKER

;;;;;;

MAX

HEADPHONE

;;;;

MAX

[ ]/[ ]:Up/Down

p

p

p

[

[ ]/[ ]:Adjust

1 SOUND MENU

G)AUDIO SET

.

MUTE TYPE

;;;

FULL

A.DELAY

;;;;;;

0ms

MAX VOL.

;;;

+16dB

INIT.VOL.

;;;;

OFF

[ ]/[ ]:Up/Down

p

p

p

[

[ ]/[ ]:Select

1 SOUND MENU

Note

Note
