 Chapter 7 WAN

NBG-418N v2 User’s Guide

79

7 .3 .2   PPPo E Enc a p sula tio n

The NBG-418N v2 supports PPPoE (Point-to-Point Protocol over Ethernet). PPPoE is an IETF standard (RFC
2516) specifying how a personal computer (PC) interacts with a broadband modem (DSL, cable,
wireless, etc.) connection. The

PPP o ve r Ethe rne t

option is for a dial-up connection using PPPoE.

For the service provider, PPPoE offers an access and authentication method that works with existing
access control systems (for example Radius).

First DNS Server

Second DNS Server

Enter the first and second DNS server's IP address in the fields.

WAN MAC Address

The MAC address section allows users to configure the WAN port's MAC address by either using the NBG-418N v2’s
MAC address, copying the MAC address from a computer on your LAN or manually entering a MAC address.

Factory default

Select this option to use the factory assigned default MAC Address.

Clone the
computer's MAC
address - MAC
Address

Select this option to clone the MAC address of the computer (displaying in the screen) from
which you are configuring the NBG-418N v2. Once it is successfully configured, the address
will be copied to the rom file. It will not change unless you change the setting or upload a
different ROM file.

Set WAN MAC
Address

Select this option and enter the MAC address you want to use.

ISP Parameters for Internet Access (Ethernet DHCP)

Connection Type

Choose the

Ethe rne t (DHC P)

option when the WAN port is used as a regular Ethernet.

Host Name

Type the domain name that is associated with this Ethernet connection.

MTU Size

Type the

MTU

 or maximum size of each data packet, in bytes, that can move through this

interface. If a larger packet arrives, the NBG-418N v2 divides it into smaller fragments. Allowed
values are 576 to 1500. By default this value is 1500.

DNS Services

Attain DNS
Automatically

Click the

A tta in DNS A uto m a tic a lly

 button if your ISP dynamically assigns DNS server

information (and the NBG-418N v2’s WAN IP address). The field to the right displays the (read-
only) DNS server IP address that the ISP assigns.

Set DNS Manually

Select

Se t DNS Ma nua lly

 if you have the IP address of a DNS server. You will need to enter the

first and secondary DNS server's IP address in the fields to the bottom.

First DNS Server

Second DNS Server

Enter the first and second DNS server's IP address in the box fields.

WAN MAC Address

The MAC address section allows users to configure the WAN port's MAC address by either using the NBG-418N v2’s
MAC address, copying the MAC address from a computer on your LAN or manually entering a MAC address.

Factory default

Select this option to use the factory assigned default MAC Address.

Clone the
computer's MAC
address - MAC
Address

Select this option to clone the MAC address of the computer (displaying in the screen) from
which you are configuring the NBG-418N v2. Once it is successfully configured, the address
will be copied to the rom file. It will not change unless you change the setting or upload a
different ROM file.

Set WAN MAC
Address

Select this option and enter the MAC address you want to use.

Apply

Click

A p p ly

 to save your changes back to the NBG-418N v2.

Reset

Click

Re se t

 to begin configuring this screen afresh.

Table 31   Network > WAN > Internet Connection: Ethernet Encapsulation (continued)

LA BEL

DESC RIPTIO N
