Appendix E Wireless LANs

NBG-418N v2 User’s Guide

208

Fig ure  1 4 6

 RTS/CTS

When station

A

 sends data to the AP, it might not know that the station

B

 is already using the channel. If

these two stations send data at the same time, collisions may occur when both sets of data arrive at the
AP at the same time, resulting in a loss of messages for both stations.

RTS/ C TS

 is designed to prevent collisions due to hidden nodes. An

RTS/ C TS

defines the biggest size data

frame you can send before an RTS (Request To Send)/CTS (Clear to Send) handshake is invoked.

When a data frame exceeds the

RTS/ C TS

value you set (between 0 to 2432 bytes), the station that wants

to transmit this frame must first send an RTS (Request To Send) message to the AP for permission to send
it. The AP then responds with a CTS (Clear to Send) message to all other stations within its range to notify
them to defer their transmission. It also reserves and confirms with the requesting station the time frame
for the requested transmission.

Stations can send frames smaller than the specified

RTS/ C TS

directly to the AP without the RTS (Request

To Send)/CTS (Clear to Send) handshake.

You should only configure

RTS/ C TS

 if the possibility of hidden nodes exists on your network and the "cost"

of resending large frames is more than the extra network overhead involved in the RTS (Request To
Send)/CTS (Clear to Send) handshake.

If the

RTS/ C TS

 value is greater than the

Fra g m e nta tio n Thre sho ld

 value (see next), then the RTS (Request

To Send)/CTS (Clear to Send) handshake will never occur as data frames will be fragmented before
they reach

RTS/ C TS

 size.

Note: Enabling the RTS Threshold causes redundant network overhead that could negatively

affect the throughput performance instead of providing a remedy.

Fra g m e nta tio n Thre sho ld

A

Fra g m e nta tio n Thre sho ld

 is the maximum data fragment size (between 256 and 2432 bytes) that can

be sent in the wireless network before the AP will fragment the packet into smaller data frames.

A large

Fra g m e nta tio n Thre sho ld

 is recommended for networks not prone to interference while you

should set a smaller threshold for busy networks or networks that are prone to interference.

If the

Fra g m e nta tio n Thre sho ld

 value is smaller than the

RTS/ C TS

 value (see previously) you set then the

RTS (Request To Send)/CTS (Clear to Send) handshake will never occur as data frames will be
fragmented before they reach

RTS/ C TS

size.
