 English |

29

Bosch Power Tools

1 609 92A 04K | (31.10.12)

– Firmly tighten the threaded rod

48

, thus fastening the

workpiece.

Adjusting Mitre Angles

To ensure precise cuts, the basic adjustment of the machine
must be checked and adjusted as necessary after intensive
use (see “Checking and Adjusting the Basic Adjustment”,
page 30).

Adjusting Standard Mitre Angles (see figure I)

For quick and precise adjustment of commonly used mitre an-
gles, detents

24

 have been provided for on the saw table:

– Loosen the locking knob

20

 in case it is tightened.

– Pull lever

21

 and rotate the saw table

15

 left or right to the

requested detent.

– Release the lever again. The lever must be felt to engage in

the detent.

Adjusting Any Mitre Angle (see figure J)

The mitre angle can be set in the range from 52 °  (left side) to
60 °  (right side).
– Loosen the locking knob

20

 in case it is tightened.

– Pull lever

21

 and at the same time push the locking bracket

19

 until it engages in the groove intended for this. The saw

table can be moved freely now.

– Turn the saw table

15

 left or right by the locking knob until

the angle indicator

23

 indicates the requested mitre angle.

For mitre angles greater than 45 ° :

Pull the saw-table extension

13

 completely outward (see

“Extending the Saw Table”, page 28).

– Tighten the locking knob

20

 again.

– To loosen the lever

21

 again (for adjusting standard mitre

angles), pull the lever upward.
The locking bracket

19

 snaps back to its original position

and lever

21

 can re-engage into the detents

24

.

Adjusting Bevel Angles

Adjusting Standard Bevel Angles (see figure K)

For quick and precise setting of frequently used bevel angles,
stops have been provided for the 0 ° , 45 ° , 22.5 °  and 33.9 °
angles.
– Loosen clamping lever

40

.

– Adjust stops

30

 or

43

 as follows:

– Swing the tool arm with the handle

8

 to the requested po-

sition.

– Tighten  clamping  lever

40

 again.

Adjusting Any Bevel Angle

The bevel angle can be set in a range from – 2 °  to +47 ° .
– Loosen clamping lever

40

.

– Turn  stop

30

 completely to the rear and pull stop

43

 com-

pletely to the front.
The complete tilting range is now available.

– Tilt the tool arm by the handle

8

 until the angle indicator

42

indicates the desired bevel angle.

– Hold the tool arm in this position and tighten clamping le-

ver

40

 again.

Starting Operation



Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.

Switching On (see figure L)

– For

starting operation

, pull the On/Off switch

7

 in the di-

rection of the handle

8

.

Note:

For safety reasons, the On/Off switch

7

 cannot be

locked; it must remain pressed during the entire operation.
The tool arm can only be guided downward by pressing lock-
ing switch

9

.

– For

sawing

, you must therefore press locking switch

9

 in

addition to pressing the On/Off switch.

Switching Off

– To

switch off

 the machine, release the On/Off switch

7

.

When not using the power tool, switch it off in order to save
energy.

Working Advice

General Sawing Instructions



For all cuts, it must first be ensured that the saw blade
at no time can come in contact with the fence, screw
clamps or other machine parts. Remove possibly
mounted auxiliary stops or adjust them accordingly.

Protect the saw blade against impact and shock. Do not sub-
ject the saw blade to lateral pressure.
Do not saw warped/bent workpieces. The workpiece must al-
ways have a straight edge to face against the fence.
Long workpieces must be underlaid or supported at their free
end.

Marking the Cutting Line (see figure M)

A laser beam indicates the cutting line of the saw blade. This
allows for exact positioning of the workpiece for sawing, with-
out having to open the retracting blade guard.
– For this, switch the laser beam on with the switch

39

.

– Align the cutting mark on your workpiece with reference to

the right-hand edge of the laser line.

Note:

Before sawing, check if the cutting line is still indicated

correctly (see “Adjusting the Laser”, page 31). The laser
beam, as an example, can misadjust due to vibrations after in-
tensive use.

Left

Right

0 °

45 ° 31.6 ° 22.5° 15 °

15 ° 22.5 ° 31.6 ° 45 ° 60 °

Mitre/Bevel
Angle

Stop

Adjustment

0 °

43

Push the stop completely to
the rear

45 °

30

Turn the stop completely to
the front

22.5 °

30

Turn the stop to the centre

33.9 °

30

Turn the stop completely to
the rear
