 English |

27

Bosch Power Tools

1 609 92A 04K | (31.10.12)

Technical Data

Assembly



Avoid unintentional starting of the machine. During as-
sembly and for all work on the machine, the power plug
must not be connected to the mains supply.

Delivery Scope

Before starting the operation of the machine for the first time,
check if all parts listed below have been supplied:
– Sliding mitre saw with premounted saw blade
– Material  clamp

29

– Allen key

34

Note:

Check the power tool for possible damage.

Before further use of the machine, check that all protective
devices are fully functional. Any lightly damaged parts must
be carefully checked to ensure flawless operation of the tool.
All parts must be properly mounted and all conditions fulfilled
that ensure faultless operation.
Damaged protective devices and parts must be immediately
replaced by an authorised service centre.

Stationary or Flexible Mounting



To ensure safe handling, the machine must be mounted
on a level and stable surface (e. g., workbench) prior to
using.

Mounting to a Working Surface (see figures A – B)

– Fasten the power tool with suitable screw fasteners to the

working surface. The mounting holes

25

 serve for this pur-

pose.

or

– Clamp the power tool with commercially available screw

clamps by the feet to the working surface.

Mounting to a Bosch Saw Stand

With the height-adjustable legs, Bosch GTA saw stands pro-
vide firm support for the power tool on any surface. The work-
piece supports of the saw stand are used for underlaying long
workpieces.



Read all safety warnings and instructions included with
the worktable.

Failure of observing safety warnings and

instructions can lead to electrical shock, fire and/or cause
serious injuries.



Assemble the worktable properly before mounting the
power tool.

Perfect assembly is important in order to pre-

vent the risk of collapsing.

– Mount the power tool in transport position on the saw

stand.

Flexible Mounting (not recommended!) (see figure C)

In exceptional cases, when it is not possible to mount the ma-
chine onto a level and stable work surface, it can be set up us-
ing the tilt protector.



Without the use of the tilt protector, the machine does
not stand safely and can tip over, especially when saw-
ing at maximum mitre/bevel angles.

– Screw the tilt protector

22

 in or out until the machine is po-

sitioned level on the working surface.

Dust/Chip Extraction

Dusts from materials such as lead-containing coatings, some
wood types, minerals and metal can be harmful to one’s
health. Touching or breathing-in the dusts can cause allergic
reactions and/or lead to respiratory infections of the user or
bystanders.
Certain dusts, such as oak or beech dust, are considered as
carcinogenic, especially in connection with wood-treatment
additives (chromate, wood preservative). Materials contain-
ing asbestos may only be worked by specialists.
– Always use dust extraction.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the mate-
rials to be worked.

Sliding Mitre Saw

GCM 8 SJL

Article number

3 601 M19 160

3 601 M19 1P0
3 601 M19 190

3 601 M19 1..

Rated power input

W

1250

1400

1600

No-load speed

min

-1

5500

5500

5500

Reduced starting current







Laser type

nm

mW

650

< 0.39

650

< 0.39

650

< 0.39

Laser class

1M

1M

1M

Weight according to EPTA-Procedure 01/2003

kg

17.3

17.3

17.3

Protection class

/

II

/

II

/

II

Permissible workpiece dimensions (maximal/minimal) see page 30.
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Dimension of suitable saw blades

Saw blade diameter

mm

210 – 216

Blade body thickness

mm

1.3 – 1.8

Mounting hole diameter

mm

30
