 | English

1 609 92A 04K | (31.10.12)

Bosch Power Tools

11

Retracting blade guard

12

Saw blade

13

Saw-Table extension

14

Fence

15

Saw table

16

Clamping lever of the saw-table extension

17

Scale for mitre angle

18

Insert plate

19

Locking bracket

20

Locking knob for various mitre angles

21

Mitre detent lever

22

Tilt protector

23

Mitre angle indicator

24

Detents for standard mitre angles

25

Mounting holes

26

Recessed handles

27

Adjustable fence

28

Locking screw of the adjustable fence

29

Material clamp

30

Stop for standard 45 ° , 22.5 °  and 33.9 °  bevel angles

31

Chip deflector

32

Depth stop

33

Locking screw for slide device

34

Allen key (5 mm)

35

Mounting holes for material clamp

36

Material stop *

37

Transport safety-lock

38

Laser warning label

39

Laser on/off switch (for marking of cutting line)

40

Clamping lever for any bevel angle

41

Scale for bevel angle

42

Indicator for bevel angle

43

Stop for 0 °  standard bevel angle

44

Spindle lock

45

Allen screw (size 5 mm) for mounting of saw blade

46

Clamping flange

47

Interior clamping flange

48

Threaded rod

49

Screws for insert plate

50

Lock screw of the material stop *

51

Clamping screw of the material stop *

52

Adjustment screw for laser position (parallelism)

53

Stop screw for 0 °  bevel angle

54

Screw for bevel angle indicator

55

Stop screw for 45 °  bevel angle

56

Screw for mitre angle indicator

57

Laser lens cover

58

Velcro strap

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Noise/Vibration Information

Measured sound values determined according to EN 61029.
Typically the A-weighted noise levels of the product are:
Sound pressure level 99 dB(A); Sound power level
112 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 61029:
a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

.

The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 61029 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 61029,
EN 60825-1 according to the provisions of the directives
2011/65/EU, 2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 05.11.2012

Dr. Egbert Schneider
Senior Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
