 English |

21

Bosch Power Tools

1 609 92A 0L0 | (16.5.14)

Laying of Square Tiles (see figure B)

Position the measuring tool in one corner so that the 0 °
laser line runs parallel to one wall. Lay the first square tile
at the crossing point of the 0 ° and the 90 ° laser lines.

Laying with Diagonal Pattern (see figure C)

Position the measuring tool so that the 45 ° laser line
marks the diagonal tile joint.

Tile laying in Kitchenettes (see figure D)

Firstly determine the height at which the first tile row
begins. Fix the measuring tool with the levelling plate

10

vertically on the wall so that the 90 ° laser line marks the
lower edge of the first tile row.

Laying from Edges (see figure E)

Position the measuring tool on the levelling plate

10

 at the

edge so that a lateral cut-out

11

 of the levelling plate is

directly at the edge. The 0 ° laser line should run parallel to
one edge. The 90 ° laser line now marks the lower tile row.

Maintenance and Service

Maintenance and Cleaning

Store and transport the measuring tool only in the sup-
plied protective pouch.

Keep the measuring tool clean at all times.

Do not immerse the measuring tool in water or other fluids.

Wipe off debris using a moist and soft cloth. Do not use
any cleaning agents or solvents.

Regularly clean the surfaces at the exit opening of the
laser in particular, and pay attention to any fluff or fibres.

If the measuring tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an authorised after-sales service centre for
Bosch power tools. Do not open the measuring tool your-
self.

In all correspondence and spare parts orders, please al-
ways include the 10-digit article number given on the type
plate of the measuring tool.

In case of repairs, send in the measuring tool packed in its
protective pouch

12

.

After-sales Service and Application Service

Our after-sales service responds to your questions con-
cerning maintenance and repair of your product as well as
spare parts. Exploded views and information on spare
parts can also be found under:

www.bosch-pt.com

Bosch’s application service team will gladly answer ques-
tions concerning our products and their accessories.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or
arrange the collection of a product in need of servicing or
repair.
Tel. Service: (0844) 7360109
E-Mail: boschservicecentre@bosch.com

Ireland

Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888
