16

 | English

1 609 92A 0L0 | (16.5.14)

Bosch Power Tools

Product Description and
Specifications

Please unfold the fold-out page with the representation of
the measuring tool and leave it unfolded while reading the
operating instructions.

Intended Use

The measuring tool is intended for determining and
checking right angles as well as for aligning tiles in angles
of 45 ° and 90 °.

Product Features

The numbering of the product features shown refers to
the illustration of the measuring tool on the graphic page.

1

Exit opening for laser beam

2

Laser warning label

3

On/Off button

4

Magnets

5

Serial number

6

Battery lid

7

Latch of battery lid

8

Battery indicator

9

Laser target plate

10

Levelling plate

11

Cut-out in the levelling plate

12

Protective pouch

13

Laser viewing glasses *

14

Ceiling measurement plate*

* Accessories shown or described are not part of the standard
delivery scope of the product. A complete overview of acces-
sories can be found in our accessories program.

Technical Data

Tile laser

GTL 3

Professional

Article number

3 601 K15 200

Working range (with laser target plate or with ceiling plate)

20 m

1)

Angular accuracy

± 0.2 mm/m

2)

Operating temperature

– 10 ° C ... + 50 ° C

Storage temperature

– 20 ° C ... + 70 ° C

Relative air humidity, max.

90 %

Laser class

2

Laser type

635 nm, < 1 mW

C

6

1

Batteries

4 x 1.5 V LR6 (AA)

Operating life time

– with  2  laser  lines
– with  3  laser  lines

18 h
12 h

Automatic switch-off after approx.

30 min

Weight according to EPTA-Procedure 01/2003

0.5 kg

1) The working range can be decreased by unfavourable environmental conditions (e. g. direct sun irradiation).

2) The angular accuracy between the 45 ° laser line and the 90 ° laser line is max. ± 0.4 mm/m.

The measuring tool can be clearly identified with the serial number

5

 on the type plate.
