5

English

1.7  Unit conversion

Please check for accessory parts as below. (Packed in the unit, and available for convertible unit only)

In the case of converting to down

fl

 ow unit, change according to the following steps.

STEP 1

STEP 2

STEP 3

STEP 4

Remove
top panel

Remove
service panel

Remove
duct

fl

 ange

Remove
duct

fl

 ange

Re-install
supply air cover

Re-install
fan assy

Remove

Remove
low cover

Remove supply
air cover

2.  Additional casing leg

(Accessory parts)

1.  Additional side inlet cover

(Accessory parts)

Re-install
top panel

Re-install
service panel

INSTALLATION OF THE UNIT

1. Side inlet cover

1 piece

2. Casing leg

2 pieces UAT(Y)(P)80, 100, 120A
4 pieces UAT(Y)(P)150, 200A
