4.

Inspecting

the

carbon

brushes

(Fig.

31)

  The motor employs carbon brushes which are

consumable parts. Since an excessively worn carbon
brush can result in motor trouble, replace the carbon
brushes with new ones having the same carbon brush
No. shown in the

fi

 gure  when  it  becomes  worn  to  or

near the “wear limit ”. In addition, always keep carbon
brushes clean and ensure that they slide freely within
the brush holders.

The number of the carbon brush will di

ff

  er in accordance

with the voltage being used.

5.

Replacing

the

carbon

brushes

  Disassemble the brush caps with a slotted-head

screwdriver. The carbon brushes can then be easily
removed. (

Fig.

32

)

CAUTION

Be careful not to deform the brush holder during this
operation.

6.

Inspecting

the

mounting

screws

Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws
be  loose,  retighten  them  immediately.  Failure  to  do  so
could result in serious hazard.

7.

Maintenance

of

the

motor

The motor unit winding is the ver y “heart ” of the power
tool.

Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.

8.

Service

parts

list

CAUTION

Repair, modi

fi

 cation and inspection of Hitachi Power

Tools must be carried out by a Hitachi Authorized
Ser vice Center.

This Parts List will be helpful if presented with the tool to
the Hitachi Authorized Ser vice Center when requesting
repair or other maintenance.

In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
countr y must be obser ved.

MODIFICATIONS

Hitachi Power Tools are constantly being improved
and modi

fi

 ed to incorporate the latest technological

advancements.

Accordingly, some parts may be changed without prior
notice.

GUARANTEE

We guarantee Hitachi Power Tools in accordance with
statutor y/countr y speci

fi

 c regulation. This guarantee does

not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the Power Tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a Hitachi Authorized Ser vice Center.

NOTE

Due to HITACHI’s continuing program of research and
development, the speci

fi

 cations herein are subject to

change without prior notice.

Information

concerning

airborne

noise

and

vibration

The measured values were determined according to
EN60745 and declared in accordance with ISO 4871.

Measured A-weighted sound power level: 103 dB (A)
Measured A-weighted sound pressure level: 90 dB (A)
Uncertainty KpA: 2 dB (A).

Wear hearing protection.

Vibration total values (triax vector sum) determined
according to EN60745.

a

h

 = 4.0 m/s

2

Uncertainty K = 1.5 m/s

2

The declared vibration total value has been measured in
accordance with a standard test method and may be used
for comparing one tool with another.
It may also be used in a preliminar y assessment of
exposure.

WARNING

◯

  The vibration emission during actual use of the power

tool can di

ff

 er from the declared total value depending

on the ways in which the tool is used.

◯

  Identify safety measures to protect the operator that

are based on an estimation of exposure in the actual
conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is
switched o

ff

  and when it is running idle in addition to the

trigger time).
