10

TV 1835 • TV 2040 • TV 2245

EN

chain brake lever.

(Fig. 9)

  8.   Chain and motor should stop immediately.

  9.   If the chain brake functions normally, switch off the

motor and return the chain brake in disengaged po

-

sition.

WARNING:

 If the chain and motor fail to stop

when the chain brake is engaged, take the saw to the

nearest  authorized  SPARKY  service  centre.  Do  not

use the saw with a faulty chain brake.

General cutting instructions

KICKBACK

(Fig. 2a)

Kickback is the sudden backward/upward motion of the

chain  saw,  occurring  when  the  chain  (at  the  tip  of  the

chain bar) comes in contact with a log or wood, or when

the chain becomes jammed.

When kickback occurs the chain saw reacts unpredict

-

ably  and  can  cause  severe  injuries  to  the  operator  or

bystanders.

Particular  attention  must  be  given  when  sawing  side-

ward, slanted or during length cuts, as the spiked bump-

er (14) usually cannot be applied.

To avoid kickback:

  -   Saw with the chain bar at a flat angle.

  -   Never  work  with  a  loose,  widely  stretched  or  the

heavily worn out chain.

  -   Ensure chain is sharpened correctly prior to opera-

tion.

  -   Never saw above shoulder height.

  -   Never work with the tip of the chain bar.

  -   Always hold the chain saw firmly with both hands.

  -   Always use a low-kickback chain.

  -   Apply the spiked bumper for leverage.

  -   Ensure correct chain tensioning.

GENERAL BEHAVIOR

Always hold the chain saw firmly with both hands, front

grip with the left hand and rear grip with the right hand.

Fully grip both handles at all times during operation. Nev-

er operate chain saw using only one hand.

Ensure  power  cord  is  located  to  the  rear,  away  from

the chain and wood and so positioned that it will not be

caught on branches or the like during cutting.

Operate the chain saw only with secure footing. Hold the

chain saw at the right-hand side of your body.

(Fig.10)

The chain must be running at full speed before it makes

contact with the wood. Use the spiked bumper to secure

the saw onto the wood before starting to cut. Use the

spiked  bumper  (14)  as  a  leverage  point  while  cutting.

(Fig.11a)

Reset the spiked bumper at a lower point when sawing

thicker logs by pulling the chain saw slightly backwards

until  the  spiked  bumper  releases,  and  repositions  at

lower level to continue sawing. Do not remove the saw

completely from the wood.

Do not force the chain while cutting, let the chain do the

work, using the spiked bumper to apply minimal leverage

pressure.

Do not operate the chain saw with arms fully extended

or  attempt  to  saw  areas  which  are  difficult  to  reach,  or

on  a  ladder.  Never  use  the  chain  saw  above  shoulder

height.

(Fig.11b)

Optimum results are achieved when the chain speed re-

mains steady during cutting.

Beware when reaching the end of the cut. The weight of

the saw in your arms may change unexpectedly as it cuts

free from the wood.

Always remove the saw from a wood cut while the saw

is running.

FELLING A TREE

(Fig.12)

WARNING:

 Always wear a safety helmet

where there is a risk of falling objects..

WARNING:

The chain saw can only be used

to fell trees smaller in diameter than the usable cutting

length of the chain bar.

WARNING:

Prior to performing the felling cut

always re-check there are no bystanders, animals or

obstacles in the vicinity of the falling tree.

WARNING:

Do not cut down a tree during

high or changing winds or if there is a danger to prop

-

erty.

When bucking and felling operations are being per

-

formed  by  two  or  more  persons,  at  the  same  time,  the

felling operations should be separated from the bucking

operation by a distance of at least twice the height of the

tree being felled. Trees should not be felled in a manner

that would endanger any person, strike any utility line or

cause any property damage. If the tree does make con

-

tact with any utility line, the company should be notified

immediately.

The chain saw operator should keep on the uphill side

of the terrain as the tree is likely to roll or slide downhill

after it is felled.

An escape path

②

. should be planned and cleared as

necessary before cuts are started. The escape path

should extend back and diagonally to the rear of the ex

-

pected line of fall

③

.

Before felling is started, consider the natural lean of the

tree, the location of larger branches and the wind direc-

tion to judge which way the tree will fall.

Remove dirt, stones, loose bark, nails staples, and wire

from the tree.

Small trees up to 15–18 cm in diameter are usually cut in

a single cut. Larger trees require notching cuts. Notching

cuts determine the direction the tree will fall.

Generally felling a tree consist of two basic operations,

notching undercut and felling back cut.

Notching undercut

Make the notch

(X – W)

 1/3 the diameter of the tree, per-
