9

Original instructions

EN

position products in the case of incomplete combustion.

Forbidden media:

 Water.

Measures against accidental release:

Protective measures:

 Wear appropriate personal protec

-

tion when cleaning up spills. For large spills use a pump

or a vacuum-truck and store in storage/salvage vessels.

For small spills soak up residue with an absorbent such

as  clay,  sand  or  other  suitable  material.  Place  in  non-

leaking container and seal tightly for proper disposal.

Handling and storage:

Do not store in open or unlabeled containers. Store in

a  cool,  dry  place  with  adequate  ventilation.  Keep  away

from open flames and high temperature.

Empty used containers retain residue (liquid and/or va-

pour) and can be dangerous. It is forbidden to pressur

-

ize,  cut,  weld,  braze,  solder,  drill,  grind  or  expose  such

containers to heat and flames.

Exposure control / Personal protection:

Provide adequate ventilation to control airborne concen-

trations below the exposure guidelines/limits.

Wear  appropriate  respirator,  chemical  goggles,  chemi-

cally  resistant  to  this  oil  protective  gloves,  protective

clothing and shoes. Wash hands with water an use cos

-

metic to protect

Operating instructions

This  power  tool  is  supplied  from  single-phase  alternat-

ing current mains only. It is double insulated according

to EN 60745 and IEC 60745 and can be connected to

grounded or not grounded sockets. This power tool is ra

-

dio suppressed in compliance with EMC Directive.

The  chain  saw  is  designed  for  cutting  wood  (trees,

planks, laths, etc.).

PRIOR TO INITIAL OPERATION

▪ Make  sure  the  power  supply  voltage  corresponds  to

the value indicated on the name plate with technical

data of the power tool.

▪

Make sure that the cord and the plug are in order. If the

replacement of the supply cord is necessary, this has

to be done by the manufacturer or his agent in order

to avoid a safety hazard.

WARNING:

 switch off and unplug the power

tool prior to any adjustment, servicing or maintenance.

▪

In case the work area is remote from the power

source,  use  as  short  as  practicable  extension  cord

with  proper  cross-section.  (1,5  mm

2

 for extension

cords shorter than 25 m; 2,5 mm

2

 or extension cords

long 25 m to 40 m).

▪

Use extension cords for outdoor use and marked

accordingly. Always fully unwind the extension cord

drum.

▪

It is recommended when operating outdoors and in

premises with high humidity to use a residual current

device  (RCD)  with  a  tripping  current  not  exceeding

30 mA.

STARTING THE CHAIN SAW

  1.   Make sure the safety chain brake lever (1) is disen-

gaged. The motor will not start if the chain brake is

in the engaged position. Disengage the chain brake

lever by pulling it backward toward the front handle

(Fig.7A)

  2.  An extension cord hook (7) is built-in the back han-

dle preventing extraction of the cord. To use this fea-

ture, simple double the extension cord, about 30 cm

from the end, and insert it into the hole of the handle.

Hook the loop formed by doubling the cord over the

cord hook. Gently tug on the cord to ensure that it

is firmly retained in the handle. Plug the receptacle

end of the extension cord into the tool power supply

cord.

(Fig.8)

  3.   Grip the machine with both hands, left hand holding

the front handle (do not hold the chain brake) and

the right hand holding the rear handle.

  4.  Press the safety lock-off button (3), then fully press

the switch trigger (4) and hold in this position.

The  safety  lock-off  button  can  be  released  now.

(Fig.7B,C).

NOTE:

It is not necessary to maintain pressure on the

lock-off  button  (3)  once  the  switch  trigger  is  squeezed

and the motor is running. The safety lock-off button (3) is

a safety device to avoid accidental starting.

STOPPING THE CHAIN SAW

The chain saw will stop automatically when the switch

trigger (4) is released. To restart the motor press the

safety lock-off button (3) and squeeze the switch trigger

(4).

CHAIN BRAKE FUNCTIONAL TEST

The chain brake is a safety mechanism actuated through

the front hand guard. When kickback occurs, chain stops

immediately.

The functional test should be carried out at regular in

-

tervals to ensure it proper operation. The purpose of the

chain brake testing is to reduce the probability of injury

due to kickback.

Check the chain brake before starting to operate the

saw, after prolonged period of operation and always dur-

ing maintenance.

NOTE:

The motor will not start if the chain brake is in the

engaged position.

CAUTION!

The chain brake should not be used for start

-

ing and stopping the saw during normal operation.

  1.   Make  sure  the  safety  chain  brake  lever  is  disen-

gaged.

(Fig.7A)

  2.   Place the chain saw on any suitable flat surface.

  3.   Plug the machine into the supply source.

 4.   Grasp the front handle with your left hand (do not

hold  the  chain  brake).  Thumb  and  fingers  should

encircle the handle.

  5.   Grasp the rear handle with your right hand. Thumb

and fingers should encircle the handle;.

  6.   Press  the  safety  lock-off  button  (3)  with  your  right

thumb,  then  fully  press  the  switch  trigger  (4)  with

your index finger and hold it in this position.

  7.   While the motor is running, activate the chain brake

lever  by  rolling  your  left  hand  forward  against  the
