8

TV 1835 • TV 2040 • TV 2245

EN

WARNING:

 The chain life depends mainly

upon sufficient lubrication and correct tensioning.

WARNING:

 Avoid tensioning a hot chain, this

will  cause  over  tensioning  of  the  chain  when  it  cools

down.

  1.   Place  the  chain  saw  on  any  suitable  flat  surface.

Screw the chain tensioning ring (10) clockwise until

the tool-free system is tightened firmly. The ratchet

mechanism prevents the chain tension from loosen-

ing.

 (Fig.5a)

  2.   Correct  chain  tension  is  achieved  when  the  chain

can be raised approximately 2-3 mm from the guide

bar in its centre. This is performed by using one

hand to raise the chain against the weight of the ma

-

chine.

 (Fig.5b)

  3.   When the chain loosens, unscrew the ring (10), and

then tighten the locking knob (11) again.

    In cases where the loosened chain needs to be ad

-

justed, always unscrew the adjustable outside ring

before  adjusting  the  chain  tensioning  screw/knob;

adjust the tension and tighten the bar retaining knob

accordingly.

NOTE:

If the chain rotates hardly on guide bar or if it

binds, too much tension has been applied. In this case

unwind  the  adjusting  ring  anti-clockwise  and  move  the

chain back and forth until it starts to move smoothly.

NOTE:

If the chain rotates hardly on guide bar

or  if  it  binds,  too  much  tension  has  been  applied.  In

this case unwind the adjusting ring anti-clockwise and

move  the  chain  back  and  forth  until  it  starts  to  move

smoothly.

Check the tension regularly because the chain tends to

stretch with use (especially when the chain is new; after

the  first  assembly,  the  chain  tension  must  be  checked

after 5 minutes machine operation); in any case do not

tighten  the  chain  immediately  after  use,  but  wait  until  it

cools down.

CHAIN AND BAR LUBRICATION

WARNING:

 The chain saw is delivered with-

out oil in the tank. It is essential to fill the tank with oil

before use. Never operate the chain saw without oil or

under the minimum admissible oil tank level. This will

result in extensive damage to the machine.

WARNING:

Never starve the bar and chain of

lubricating oil. Running the chain saw dry or with too

little oil will decrease cutting efficiency, shorten chain

saw life, and cause premature chain dulling resulting in

excessive wear of the bar from overheating. The lack

of oil is evidenced by smoke and bar discolouration.

Adequate lubrication of the saw chain during cutting

operations is essential to minimize friction with the

guide bar. The chain saw is equipped with an automatic

oiler system. The oiler automatically delivers the proper

amount of oil to the bar and chain.

The oil tank holds 120 mI of oil, enough to lubricate the

chain for 15-20 minutes of cutting. Check oil level gauge

(12) prior to starting and regularly during operation. Refill

oil when oil level is lower than “MIN” marking.

Filling the oil tank

(Fig.6)

  1.   Place the chain saw on any suitable surface with the

oil tank cap (13) facing upward.

  2.   Clean the area around the cap with a piece of cloth.

Unscrew the tank cap.

  3.   Add chain saw oil until the tank is full.

  4.   Avoid  dirt  and  debris  entering  the  tank.  Fit  the  cap

and tighten it.

WARNING:

It is important to use only the recommended

oil  to  avoid  damage  to  the  chain  saw.  The  use  of  recy-

cled/old oil will invalidate the warranty.

CAUTION!

The  oil  tank  level  should  be  frequently

checked during operation to avoid starving the bar and

chain of lubrication.

NOTE:

Your chain saw is equipped with an automatic

oiler system and which is the only source of lubrication

for the bar and saw chain.

Hydraulic oil information

and safety requirements

during operation

Product name:

Anti-wear hydraulic oil

General features:

 Liquids can be dissolved in oil.

Use:

Anti-wear  hydraulic  oil  can  be  used  in  equipment

for lubrication, cooling, air-proofing, etc.

Potential health hazards:

There  is  sufficient  evidence  for  carcinogenicity  under

laboratory conditions. Under normal conditions of in

-

tended use this product does not pose a risk to health.

Excessive exposure may result in eye, skin or respiratory

irritation.

First-aid measures:

Upon contact with eyes, flush them with water for 15 min-

utes. Get medical attention if irritation occurs.

Upon skin contact flush skin with water, and then wash

with soap and water. Get medical attention.

Inhalation  of  sprayed  oil  is  harmful.  Move  the  injured

person to fresh air and provide oxygen. Get medical at-

tention.

Harmful if swallowed. Wash hydraulic oil from your

mouth but do not induce vomiting. Get medical attention.

Notes to physician:

Cure according to the symptoms.

Fire fighting measures:

Extinguishing media:

 Carbon dioxide, foam, dry chemi-

cals and water fog.

Extinguishing method: Spray.

Combustion products:

  Fumes,  smoke,  carbon

monoxide,sulphur oxides,  aldehydes and other  decom-
