18

is sharpened. Clean the guide bar groove and oil holes on that
occasion. Guide bar groove is rectangular. Check the groove
against wear. Put rule to guiding strip and outer sur face of a
chain tooth.

I

f you obser ve distance between, the groove is

correct. Other wise the guide bar is worn out and needs to be
replaced.

C H A I N  W H E E L

Driving chain wheel is subject to especially heavy wear. Replace
the chain wheel when you obser ve clear signs of wear of wheel
teeth. Worn chain wheel additionally reduces durability of chain.
Chain wheel should be replaced by authorised ser vice workshop.

A D J U S T M E N T  O F  C A R B U R E T TO R

Chain saw carburettor is factor y set, however it may require
precise adjustment when operating conditions change. Before
star ting to adjust the carburettor ensure new air filter and fuel
filter are installed and tank is filled with appropriate fuel blend.

A

djust the carburettor with guide bar and chain installed.

•

Screw in both adjustment screws (L and H) (

16

) until stop (do

not over tighten) (

fig. G

).

•

First, unscrew two adjustment screws (

16

) as specified below :

-

L screw : by 1 1/4 of a turn

-

H screw : by 1 3/8 of a turn

•

Star t up the engine and allow it to heat up while holding
throttle lever (

11

) pressed in half.

•

A

fter the engine has been heated, release pressure on the

throttle lever (

11

) and allow the engine to run slowly.

•

Turn the screw (

L

) slowly clockwise until idle run achieves its

maximum speed, then turn the screw counter-clockwise by
1/4 of a turn.

•

Turn low speed adjustment screw (

T

) (

17

) counter-clockwise

until the chain stops moving. When slow speed appears to be
too low, turn the screw clockwise (

fig. G

).

Avoid touching the muffler. Hot muffler may cause severe
burns.

C H A I N  B R A K E

The saw features automatic brake, which stops the chain in
case of recoil during chain saw operation. The brake engages
automatically when force of iner tia is applied to a weight located
inside the brake casing. The chain brake can also be switched on
manually, when the brake lever (

6

) is moved towards the guide

bar (

20

). Switching the chain brake stops the chain movement

in 0.12 sec.

B R A K I N G  C H E C K

Ensure the brake operates correctly before each use of the saw.

•

Put operating saw on the ground and open the throttle fully
for 1 – 2 seconds to allow the saw engine to operate at its
maximum speed.

•

Push the brake lever (

6

) for ward. The chain should stop

immediately.

•

I

n case the chain stops slowly or does not stop at all, replace

the brake band and clutch drum before using the chain saw
again.

•

To release the brake, pull the brake lever (

6

) towards the

main handle (

12

) so you can hear sound typical of blockade

snapping.

Ensure the chain brake operates correctly and the chain is
sharp. It is ver y impor tant for keeping potential recoil at a safe
level.

C H E C K I N G  B R A K E  E N G AG E M E N T

During this check the saw engine should be switched off.

•

Lift the saw while holding the front handle (

5

) and main

handle (

12

) approximately 35 cm above wooden object.

•

Let the front handle (

5

) go and allow the guide bar to tilt under

its own weight and touch the wooden object (

fig. H

).

•

A

t the contact with the wooden object, the chain brake should

engage (brake lever (

6

) moves for ward to the O

N

 position).

Ensure the chain brake operates correctly before star ting any
task. In case the brake does not operate efficiently, adjust it or
repair in authorized ser vice site.

In case the engine operates at high speed with the chain brake
switched on, the saw clutch will overheat. When the chain
brake engages during operation of the engine, release the
throttle lever immediately and keep engine speed at low level.

C H A I N  T E N S I O N  A D J U S T M E N T

Cutting chain tends to lengthen during operation due to higher
temperature. Longer chain loosens and may slip off the guide
bar.

•

Loosen the guide bar fixing nuts (

7

).

•

Ensure the chain (

21

) remains in the guiding groove of the

guide bar (

20

).

•

Use a screwdriver to turn the chain tension adjustment screw
(

8

) clockwise, until the chain is strained appropriately (it

should slightly hold the guide bar in horizontal position).

•

Check the chain tension again (it should be possible to lift the
chain by approximately 3 – 4 mm in the middle of the guide
bar) (

fig. I

).

•

Tighten firmly the guide bar fixing nuts (

7

).

Do not over-tension the chain. Adjustment of overly heated
chain may lead to excessive tension when cooling down.

O P E R AT I N G T H E  C H A I N  S AW

•

Before star ting any planned task, familiarize yourself with
section describing safe rules for chain saw operation.

I

t is

recommended to gain experience by cutting waste wood
pieces.

I

t will also allow to find out the chain saw possibilities.

•

A

lways obser ve safety regulations.

•

Use the chain saw only for cutting wood. Cutting other
materials is forbidden.

•

I

ntensity of vibrations and recoil change depending on the

type of wood being cut.

•

Do not use the chain saw as a lever to lift, move or split
objects. When the chain is pinched in wood, switch off the
engine and drive wooden or plastic wedge into the processed
piece to release the chain saw (

fig. J

). Star t the tool again and

commence cutting carefully.

•

Do not fix the saw to a stationar y work station.

•

A

ttaching other devices, which are not allowed by the chain

saw manufacturer, to the chain saw drive is forbidden.

•

I

t is not necessar y to apply big force to the chain saw when

using the tool.

A

pply light pressure only while the engine

operates with the throttle fully opened.

When the chain saw is pinched in ker f during cutting, do not

remove it forcefully. It may cause loss of control over the chain
saw, operator injur y and/or damage to the chain saw.

Release the chain brake before star ting to work.

•

Press the throttle lever lock (

1

) and throttle lever (

11

) (wait

until engine reaches its full speed before star ting to cut).

•

Keep maximum speed for the whole time.

•

A

llow the chain to cut wood. Press down the saw lightly (

fig.

K

).

•

Stop pressing the saw at the end of the cut to avoid loosing
control over the tool.

•

When the cutting has been finished release the throttle lever
(

11

) and allow the engine to run idle.

•

Switch off the engine before putting the chain saw away.

Keeping high speed of the engine when not cutting wood
causes unnecessar y losses and wear of par ts.

P R OT E C T I O N  AG A I N S T  R E CO I L

Recoil is movement of the guide bar of the chain saw up and/or
back, which happens when the par t of the chain on the guide
bar tip encounters an obstacle.
