16

•

Operating saw tends to rotate when tip of the chain guide
bar touches processed material.

I

n such case the saw may get

out of control and move towards the operator (

risk of body

injury!

).

•

The tree cuttings should be preceded with preparation of
the work place consisting of the removal of lower inter fering
branches and clearing the area around the tree trunk.

•

Do not work in strong wind, which may influence the predicted
tree falling direction and cause its uncontrolled felling.

•

Do not carr y out cuttings in conditions of limited visibility,
when it is foggy, rains or snows.

•

Do not overreach and do not cut above your shoulder height,
or when standing on a tree, ladder, scaffold, trunk, etc.

•

A

 well-equipped first aid kit should be available near the work

place.

To prevent saw recoil follow below instructions:

•

N

ever star t or guide a cut with the tip of the guide bar!

•

A

lways star t cutting with saw previously switched on!

•

Ensure the cutting chain is sharp.

•

N

ever cut more than one branch at a time. When cutting off,

watch out for surrounding branches. When cutting a tree
through, watch out for nearby tree trunks.

Explanation of used symbols

1.

Caution, use precaution measures

2.

Fire hazard

3.

Exhaust gas poisoning hazard

4.

Use protective gloves

5.

Switch off the engine and remove wire from the ignition
plug before commencing any maintenance or repair

6.

Read instruction manual, obser ve warnings and safety
conditions therein!

7.

Use head, eyes and ears protection

8.

Danger of recoil

9.

Use protective clothes

10.

Use protective shoes

11.

Do not put your hands or legs close to cutting par ts

CONSTRUC TION AND USE

Petrol chain saw is a hand-held tool.

I

t is driven by an air cooled,

two-stroke combustion engine. Tool of this type is designed for
tasks in home garden. The saw can be used for cutting down
trees, cutting branches, firewood, wood for fireplace and other
tasks where cutting wood is necessar y.

Use the device according to the manufacturer ’s instructions
only.

D E S C R I P T I O N  O F  D R AW I N G  PAG E S

Below enumeration refers to the device elements depicted on
the drawing pages of this manual.

1.

Throttle lever lock

2.

Choke cable

3.

Knob for air filter lid

4.

A

ir filter lid

5.

Front handle

6.

Brake lever

7.

Guide bar fixing nuts

8.

Chain tension adjustment screw

9.

Oil feed adjustment screw

10.

Casing

11.

Throttle lever

12.

M

ain handle

13.

Star ter line

14.

I

gnition switch

15.

Fuel filler plug

16.

Carburettor adjustment screws, L and H

17.

Low speed adjustment screw T

18.

Oil filler plug

19.

Bumper spike

20.

Guide bar

21.

Chain

22.

Guide bar chain wheel

* Differences may appear between the product and drawing.

M E A N I N G  O F  S YM B O L S

  C

A

UT

I

O

N

  W

A

R

NIN

G

A

SSE

M

BLY/SET T

IN

GS

IN

FOR

MA

T

I

O

N

E Q U I PM E N T  A N D  ACC E S S O R I E S

1.

Guide

bar

guard

     -

1

pc

2.

Guide

bar

      -

1

pc

3.

Cutting

chain

     -

1

pc

4.

Bumper spike + bolts

- 1 set

5.

Fuel and oil mix tank

- 1 pc

6.

Sparking plug wrench with screwdriver

- 1 pc

7.

Screwdriver

      -

1

pc

8.

Hexagonal

key

     -

2

pcs

9.

File         -

1

pc

PREPARATION FOR OPERATION

C A R RYI N G T H E  C H A I N  S AW

Prior to carr ying the chain saw slide chain cover onto guide
bar and chain. When carr ying the chain saw, hold it by front
handle. Do not carr y the saw when holding main handle. If
several cuttings are to be made, switch off the chain saw with
the ignition switch between consecutive tasks.

I N S TA L L I N G T H E  B U M P E R  S P I K E

The bumper spike should be attached to the chain saw at all

times due to safety reasons. The bumper spike is a suppor t
point and reduces the kickback risk.

•

Fasten the bumper spike (

19

) to the chain saw case using bolts

(included).

I N S TA L L AT I O N  O F  G U I D E  B A R  A N D  S AW  C H A I N

Prior to guide bar installation remove plastic transpor t spacer,
placed on guide fixing screws under the guard. Use pin and
adjustment screw for adjustment of chain tension. It is ver y
impor tant that the bolt located on adjustment screw falls into
hole in the guide bar during installation of the guide bar.

You can move the bolt to the front and back by turning the
adjustment screw. Those par ts must be set appropriately prior
to star ting guide bar installation in the saw.
