Technical Data

Assembly

Mounting the Protective Devices

f

Before any work on the machine itself, pull

the mains plug.

Note:

After breakage of the grinding disc during

operation or damage to the holding fixtures on

the protection guard/power tool, the machine

must promptly be sent to an after-sales service

agent for maintenance (for addresses, see sec-

tion „After-sales Service and Customer Assist-

ance“.

Protection Guard for Grinding

Release the clamping lever

8

. Place the protec-

tion guard

6

 with the encoding key

7

 engaging

into the groove on the spindle collar until the

shoulder of the protection guard is seated

against the flange of the power tool, and turn

the protection guard

6

 to the requested posi-

tion. Lock the clamping lever

8

.

f

Adjust the protection guard 6 in such a man-

ner that sparking is prevented in the direc-

tion of the operator.

The tightening tension of the clamp from the

protection guard

6

 can be changed by loosening

or tightening the adjustment screw

9

. Ensure

that the protection guard

6

 is tightly seated and

check regularly.

Angle Grinder

GWS ...

Professional

22-180

 LVI

22-230

 LVI

24-180

 LVI

24-230

 LVI

Article number

3 601 ... H90 D.. H91 C..

H91 D..

H92 F..

H93 F..

H93 H..

Rated power input

W

2 200

2 200

2 400

2 400

Output power

W

1 500

1 500

1 600

1 600

Rated speed

rpm

8 500

6 500

8 500

6 500

Grinding disc diameter, max.

mm

180

230

180

230

Thread of grinder spindle

M 14

M 14

M 14

M 14

Thread length (max.) of grinder spindle

mm

25

25

25

25

Kickback stop

z

z

z

z

Restarting Protection

z

z

z

z

Reduced starting current

z

z

z

z

Rotatable main handle

–

–

z

z

Weight according to EPTA-Procedure

01/2003

kg

5.3

5.4

5.4

5.5

Protection class

/

II

/

II

/

II

/

II

The values given are valid for nominal voltages [U] of 230/240 V. For lower voltage and models for specific countries,
these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines
may vary.
