 | English

1 609 929 L56 | (4.6.08)

Bosch Power Tools

Product Features

The numbering of the product features refers to

the illustration of the machine on the graphics

page.

1

Spindle lock button

2

Vibration damper

3

On/Off switch

4

Auxiliary handle

5

Grinder spindle

6

Protection guard for grinding

7

Encoding key

8

Clamping lever for protection guard

9

Screw for adjustment of protection guard

10

Mounting flange with O-ring

11

Grinding/cutting disc *

12

Clamping nut

13

Quick-clamping nut

*

14

Protection guard for cutting *

15

Hand guard *

16

Spacer discs *

17

Rubber sanding plate *

18

Sanding sheet *

19

Round nut *

20

Cup brush *

21

Cutting guide with dust extraction protec-

tion guard *

22

Diamond cutting disc *

* The accessories illustrated or described are not in-
cluded as standard delivery.

Noise/Vibration Information

Measured values determined according to

EN 60745.
Typically the A-weighted noise levels of the

product are: Sound pressure level 92 dB(A);

Sound power level 103 dB(A). Uncertainty

K = 3 dB.

Wear hearing protection!

Vibration total values (triax vector sum) deter-

mined according to EN 60745:

Surface grinding: Vibration emission value

a

h

= 4.5 m/s

2

, Uncertainty K = 1.5 m/s

2

,

Disk sanding: Vibration emission value

a

h

= 3.5 m/s

2

, Uncertainty K = 1.5 m/s

2

.

The vibration emission level given in this informa-

tion sheet has been measured in accordance with

a standardised test given in EN 60745 and may be

used to compare one tool with another. It may be

used for a preliminary assessment of exposure.

The declared vibration emission level repre-

sents the main applications of the tool. However

if the tool is used for different applications, with

different accessories or poorly maintained, the

vibration emission may differ. This may signifi-

cantly increase the exposure level over the total

working period.

An estimation of the level of exposure to vibra-

tion should also take into account the times

when the tool is switched off or when it is run-

ning but not actually doing the job. This may sig-

nificantly reduce the exposure level over the to-

tal working period.

Identify additional safety measures to protect

the operator from the effects of vibration such

as: maintain the tool and the accessories, keep

the hands warm, organisation of work patterns.

Declaration of Conformity

We declare under our sole responsibility that

the product described under “Technical Data” is

in conformity with the following standards or

standardization documents: EN 60745 accord-

ing to the provisions of the directives

2004/108/EC, 98/37/EC (until Dec. 28, 2009),

2006/42/EC (from Dec. 29, 2009 on).
Technical file at:

Robert Bosch GmbH, PT/ESC,

D-70745 Leinfelden-Echterdingen

28.01.2008, Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

Dr. Egbert Schneider

Senior Vice President

Engineering

Dr. Eckerhard Strötgen

Head of Product

Certification
