UEFI BIOS

UEFI BIOS

MSI UEFI BIOS is compatible with UEFI (Unified Extensible Firmware Interface)

architecture. UEFI has many new functions and advantages that traditional BIOS

cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI

BIOS uses UEFI as the default boot mode to take full advantage of the new chipset

capabilities.

⚠

Important

The term BIOS in this user guide refers to UEFI BIOS unless otherwise noted.

UEFI advantages

∙

Fast booting - UEFI can directly boot the operating system and save the BIOS self-

test process. It can also eliminate the time to switch to CSM mode during POST.

∙

Supports for hard drive partitions larger than 2 TB.

∙

Supports more than 4 primary partitions with a GUID Partition Table (GPT).

∙

Supports unlimited number of partitions.

∙

Supports full capabilities of new devices - new devices may not provide backward

compatibility.

∙

Supports secure startup - UEFI can check the validity of the operating system to

ensure that no malware tampers with the startup process.

Incompatible UEFI cases

∙ 32-bit Windows operating system

 - this motherboard supports only Windows 10/

Windows 11 64-bit operating system.

∙

Older graphics card

 - the system will detect your graphics card. If you use older

graphics cards, it may display a warning message

There is no GOP (Graphics Output

protocol) support detected in this graphics card

.

⚠

Important

We recommend that you replace it with a graphics card supporting GOP/UEFI or use

CPU with integrated graphics for having normal function.

How to check the BIOS mode?

1.

Power on your computer.

2.

Press

Delete

 key when the

Press DEL key to enter Setup Menu, F11 to enter Boot

Menu

 message appears on the screen during the boot process.

3.

After entering the BIOS, you can check the

BIOS Mode

 at the top of the screen.

BIOS Mode:

UEFI
