76

71.06199.02 - EN

INSTALLATION INSTRUCTIONS

Description of parameters

Factory settings

24 BIC FF

24 BIC

F01

Type of boiler

10

 = sealed chamber

20

 = atmospheric chamber

10

20

F02

Gas used

00

 = METHANE

01

 = LPG

02

 = METHANE (WITH DIAPHRAGM)

02

F03

Hydraulic system

15

F04

Setting programmable relay 1 (See SERVICE instructions)

00

 = no associated function

01

 = condominium alarm

02

 = ambient fan

03

 = not used

04

 = zone pump controlled by room thermostat (230V)

05

 = not used

04

F05

Setting programmable relay 2 (DHW pump)

03

F06

Maximum CH setpoint (°C)

00

 = 85°C -

01

 = 45°C (function unavailable)

00

F07

DHW inlet priority coniguration

00

F08

CH max. output

(0-100%)

100

F09

DHW max. output

(0-100%)

100

F10

Min. heating output

(0-100%)

00

F11

Delay prior to new ignition in CH mode

(00-10 minutes) - 00=10 seconds

03

F12

Diagnostics (See SERVICE Instructions)

--

F13-F14-F15

Factory settings (no change)

00

F16

Anti-legionella function

00

 = disabled

55...67

 = enabled (setpoint °C)

00

F17

CH pressure sensor selection

00

 = hydraulic pressure sensor

01

 = hydraulic differential pressure sensor

00

F18

Manufacture information

00

21. PARAMETER SETTINGS

To set the boiler parameters, press (

–

  ) and (

–

) together and hold down for at least 6 seconds. When the function is

activate, the “

F01

” appears on the display alternating with the value of the parameter shown.

Edit parameters

•  Press  (

+/–

) to scroll through the parameters;

•  Press  (

+/–

) to edit each parameter;

•  Press

 (

)

, to save the changes. “

MEM

” appears on the display;

•  Press

(

i

)

,

 to exit without saving. “

ESC

” appears on the display.

22. ADJUSTMENT AND SAFETY DEVICES

The boiler has been designed in full compliance with European reference standards and in particular is itted with the
following:

•  Air pressure switch (model 24

BIC FF)

  This device only allows the burner to ignite if the exhaust lue duct is in perfect working order.
  In the event of one or more of the following faults:

•  lue terminal obstructed
•  venturi tubes obstructed
•  fan blocked
•  venturi tube connection - pressure switch tripped

the boiler remains on standby and error code E03 is displayed (see table in section 10).
