63

71.06199.02 - EN

OPERATING INSTRUCTIONS

To turn off the boiler, disconnect the electric power supply. In “OFF” mode (section 5) the boiler remains off (the display
indicates OFF) though the electrical circuits remain live and the frost protection device is enabled (section 9).

7. TURNING OFF THE BOILER

8. GAS CONVERSION

The boilers can operate both on natural gas and

LPG

.

All gas conversions must be made by an authorised Service Engineer.

The boiler is itted with a hydraulic pressure gauge which prevents the boiler from working if there is no water.

N.B.:

 In case pressure drops occur frequently, have the boiler checked by an authorised Service Engineer.

A:

System emptying tap

B:

 Boiler emptying tap

C:

 System illing tap

D:

 Pressure gauge

Figure 2

Do not drain the whole system as illing up with water again causes unnecessary and harmful scale to build up inside the

boiler and the heating elements. If the boiler is not used during winter and is therefore exposed to the danger of frost, add

some speciic anti-freeze to the water in the system (e.g.: propylene glycol coupled with corrosion and scale inhibitors).

The electronic boiler management system includes a “frost protection” function for the heating system which, when delivery

temperature falls below 5°C, operates the burner until a delivery temperature of 30°C is reached.

The frost protection function is enabled if:

*   the boiler is electrically powered;

*   the gas tap is open;

*   the system is at the correct pressure;

*   the boiler is not blocked.

9. PROLONGED SHUTDOWN. FROST PROTECTION
