SPECIFICATIONS

18

POWER SECTION

• Minimum RMS Output Power

(8

Ω

, 20 Hz to 20 kHz, 0.019% THD)

[AX-497]  ..............................................................  85 W + 85 W
[AX-397]  ..............................................................  60 W + 60 W

(6

Ω

, 20 Hz to 20 kHz, 0.038% THD)

[AX-497]  ..........................................................  100 W + 100 W
[AX-397]  ..............................................................  70 W + 70 W

• Dynamic Power (IHF) (8/6/4/2

Ω

)

[AX-497] .......................................................  130/150/185/220 W
[AX-397] .......................................................  100/120/140/150 W

• Maximum Output Power

(1 kHz, 0.7% THD, 4

Ω

) [U.K. and Europe models only]

[AX-497]  .........................................................................  120 W
[AX-397]  ...........................................................................  95 W

(1 kHz, 10% THD, 8/6

Ω

)

[AX-497]

[Asia, General, China and Korea models only]  ....  130/150 W

[AX-397]

[Asia, General and China models only]  ................  100/110 W

• IEC Output Power [U.K. and Europe models only]

(1 kHz, 0.019% THD, 8

Ω

)

[AX-497]  .........................................................................  100 W
[AX-397]  ...........................................................................  75 W

• Power Band Width

[AX-497] (0.04% THD, 42.5 W, 8

Ω

)  ................. 10 Hz to 50 kHz

[AX-397] (0.04% THD, 30 W, 8

Ω

)  .................... 10 Hz to 50 kHz

• Damping Factor

20 Hz to 20 kHz, 8

Ω

..................................................240 or more

• Maximum Input Signal

PHONO (1 kHz, 0.003% THD)  ..........................  115 mV or more
CD, etc. (1 kHz, 0.5% THD) ...................................  2.2 V or more

• Frequency Response

CD, etc. (20 Hz to 20 kHz)  ..........................................  0 ± 0.5 dB
CD/DVD DIRECT AMP ON (10 Hz to 100 kHz)  ......  0 ± 1.0 dB

• RIAA Equalization Deviation

PHONO  ...........................................................................  ± 0.3 dB

• Total Harmonic Distortion

PHONO to OUT (REC)

(20 Hz to 20 kHz, 3 V

)

.......................................... 0.003% or less

CD, etc. to SP OUT

(20 Hz to 20 kHz, 42.5 W, 8

Ω

)

............................. 0.009% or less

• Signal to Noise Ratio (IHF-A Network)

PHONO (input shorted)  .......................................... 88 dB or more
CD (input shorted)

CD/DVD DIRECT AMP ON  ............................ 110 dB or more

• Residual Noise (IHF-A Network)

[AX-497]

CD/DVD DIRECT AMP ON  ..........................................  35 µV
PURE DIRECT ON  .........................................................  90 µV

[AX-397]

CD/DVD DIRECT AMP ON  ..........................................  35 µV
CD/DVD DIRECT AMP OFF  .......................................  100 µV

CONTROL SECTION

• Input Sensitivity/Input Impedance

PHONO  .................................................................. 3.0 mV/47 k

Ω

CD, etc.  .................................................................. 150 mV/47 k

Ω

• Output Level/Output Impedance

OUT (REC)

[AX-497]  ...............................................  195 mV/1.6 k

Ω

 or less

[AX-397]  ...............................................  165 mV/1.6 k

Ω

 or less

• Headphone Output/Impedance

CD, etc. (Input 1 kHz, 150 mV, 8

Ω

 , 0.019% THD)

[AX-497]  ................................................................ 0.3 V/680

Ω

[AX-397] .............................................................. 0.25 V/680

Ω

• Channel Separation

CD, etc. (5.1 k

Ω

 input shorted, 1/10 kHz)  .......  65/50 dB or more

• Tone Control Characteristics

BASS

Boost/Cut (20 Hz) ...........................................................  ±10 dB
Turnover Frequency ........................................................  350 Hz

TREBLE

Boost/Cut (20 kHz) .........................................................  ±10 dB
Turnover Frequency .......................................................  3.5 kHz

• Continuous Loudness Control

Attenuation (1 kHz)  ...........................................................  –30 dB

GENERAL

• Power Supply

[U.S.A. and Canada models]  .............................  AC 120 V, 60 Hz
[Asia model]  ..................................  AC 220/230–240 V, 50/60 Hz
[General model]  ...............  AC 110/120/220/230–240 V, 50/60 Hz
[China model]  ....................................................  AC 220 V, 50 Hz
[Korea model] (AX-497 only) ............................  AC 220 V, 60 Hz
[Australia model]  ...............................................  AC 240 V, 50 Hz
[U.K. and Europe models]  .................................  AC 230 V, 50 Hz

• Power Consumption

[AX-497]

[U.S.A. and Canada models]  .............................  220 W, 300 VA
[Asia model]  ....................................................................  190 W
[Other models]  .................................................................  220 W

[AX-397] ............................................................................  170 W

• Standby Power Consumption

[Asia and General models]

(110/120 V)......................................................................... 1.1 W
(220/230-240 V) ................................................................. 2.7 W

[Other models]  .....................................................................  1.1 W
(The power consumption is 0 W when the POWER switch is
released outward to the OFF position.)

• Maximum Power Consumption [General models only]

(1 kHz, 6

Ω

 , 10% THD)

[AX-497] .........................................................................  490 W
[AX-397] .........................................................................  400 W

• AC Outlets

[U.K. and Australia models] ...............  1 (Total 100 W maximum)
[Korea model] .......................................................................  None
[General model] ...................................... 3 (Total 50 W maximum)
[Other models]  ....................................  3 (Total 100 W maximum)

• Dimensions (W x H x D)  ................................. 435 x 151 x 390 mm

• Weight

[AX-497] .............................................................................  9.1 kg
[AX-397] .............................................................................  8.3 kg

* Specifications are subject to change without notice.
