Declaration of Conformity

We declare under our sole responsibility that
the product described under “Technical Data” is
in conformity with the following standards or
standardization documents: EN 60745 accord-
ing to the provisions of the directives
2004/108/EC, 2006/42/EC.
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

10.02.2010

Assembly

Mounting the Protective Devices

f

Before any work on the machine itself, pull
the mains plug.

Note:

After breakage of the grinding disc during

operation or damage to the holding fixtures on
the protection guard/power tool, the machine
must promptly be sent to an after-sales service
agent for maintenance (for addresses, see sec-
tion „After-sales Service and Customer
Assistance“.

Protection Guard for Grinding

Place the protection guard

5

 on the spindle col-

lar. Adjust the position of the protection guard

5

to the requirements of the operation and lock
the protection guard

5

 with the locking screw

6

.

f

Adjust the protection guard 5 in such a man-
ner that sparking is prevented in the direc-
tion of the operator.

Protection Guard for Cutting

f

For cutting with bonded abrasives, always
use the protection guard for cutting 12.

f

Provide for sufficient dust extraction when
cutting stone.

The protection guard for cutting

12

 is mounted

in the same manner as the protection guard for
grinding

5

.

Cutting Guide with Dust Extraction Protection
Guard

The cutting guide with dust extraction protec-
tion guard

23

 is mounted in the same manner as

the protection guard for grinding

5

.

Auxiliary Handle

f

Operate your machine only with the auxilia-
ry handle 3.

Screw the auxiliary handle

3

 on the right or left

of the machine head depending on the working
method.

Hand Guard

f

For operations with the rubber sanding
plate 19 or with the cup brush/wheel
brush/flap disc, always mount the hand
guard 17.

The hand guard

17

 is fastened with the auxiliary

handle

3

.

Mounting the Grinding Tools

f

Before any work on the machine itself, pull
the mains plug.

f

Grinding and cutting discs become very hot
while working; do not touch until they have
cooled.

Clean the grinder spindle

4

 and all parts to be

mounted.
For clamping and loosening the grinding tools,
lock the grinder spindle with the spindle lock
button

1

.

f

Actuate the spindle lock button only when
the grinder spindle is at a standstill.

Other-

wise, the machine may become damaged.

Dr. Egbert Schneider
Senior Vice President
Engineering

Dr. Eckerhard Strötgen
Head of Product
Certification
