 | English

1 609 92A 0N2 | (5.6.14)

Bosch Power Tools

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-3.

Typically the A-weighted noise levels of the product are:
Sound pressure level 82 dB(A); Sound power level 93 dB(A).
Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Surface grinding: a

h

= 6.0 m/s

2

, K = 1.5 m/s

2

,

Disk sanding: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-3.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 12.05.2014

Assembly

Battery Charging



Use only the battery chargers listed on the accessories
page.

Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.



Do not continue to press the On/Off switch after the
machine has been automatically switched off.

The bat-

tery can be damaged.

Observe the notes for disposal.

Angle Grinder

GWS 18 V-LI

GWS 18-125 V-LI

Article number

3 601 J3A 300

3 601 J3A 301

Rated voltage

V=

18

18

Rated speed

min

-1

10 000

10 000

Grinding disc diameter, max.

mm

115

125

Thread of grinder spindle

M 14

M 14

Thread length (max.) of grinder spindle

mm

22

22

Weight according to EPTA-Procedure 01/2003

kg

2.1/2.3 *

2.1/2.3 *

Permitted ambient temperature

– during charging
– during operation

**

 and during storage

° C
° C

0 ... + 45

– 20 ... + 50

0 ... + 45

– 20 ... + 50

Recommended batteries

GBA 18 V ...

GBA 18 V ...

Recommended chargers

AL 18..

GAL3680

AL 18..

GAL3680

* dependent of the battery pack being used

** Limited performance at temperatures < 0 ° C

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
