26

en

Fruit press attachment

3.

Insert worm gear into the housing.

4.

Insert grinding ring into the housing.
Note shape of the parts!

5.

Insert grinding cone with the square
shaft into the corresponding opening of
the worm gear.

6.

Place grinding chamber on the housing.
Recess on the grinding chamber must
be situated on the lug on the housing.

7.

Fit the threaded ring onto the housing
and screw tight in the clockwise
direction without using force.

Use

W

Risk of injury!

■

Do not reach into the feed chute with
your hands.

■

Do not look into the feed chute during
operation, as the bouncing particles can
hurt your eye.

Caution!

When the mill is attached, never use reverse
function. Attachment may be damaged!

X

Fig.

L

1.

Fit the prepared attachment onto the
drive of the base unit, holding it at an
angle.

2.

Turn the attachment anticlockwise until
you hear it click into position. Tighten
threaded ring.

3.

Fit the filling tray.

4.

Place a suitable container under the
attachment. Fill the filling tray.

X

 “Tips”

see page 28

Caution!

Never allow the grain mill attachment to run
without ingredients.

5.

Set the degree of grinding by turning the
setting ring:
– anticlockwise = coarser grain
– clockwise = finer grain
Always select a value between:
– STOP = coarsest degree of grinding
– 1 = finest degree of grinding (never
use it at the beginning)

STOP

1

6.

Connect the mains plug. Switch on the
appliance.

Caution!

The appliance may be operated
continuously for a maximum of 15 minutes.
Then leave the appliance to cool down for
45 minutes!

7.

The flour trickles through the discharge
chute.

8.

Degree of grinding can be re-adjusted in
small steps during operation.

Caution!

Setting it beyond the STOP line during
operation can damage the appliance.

9.

Once you have finished, switch off the
appliance and pull out the mains plug.

10.

Remove the filling tray.

11.

Hold down the release button and
turn the attachment clockwise until it
disengages.

12.

Remove the attachment, take it apart
and clean all parts.

X

 “Care and daily

cleaning” see page 27

Fruit press attachment

For squeezing juice out of fruits such as
e.g. raspberries, currants, strawberries,
gooseberries or grapes and tomatoes.

Preparation

Note:

 selection of the filter insert

determines the content of fruit pulp in the
juice. Do not press fruit whose pips are
similar in diameter to the hole diameter in
the filter insert (e.g. raspberries).

X

Fig.

M

■

Make sure that the sealing rings are
fitted onto the filter holder and the worm
gear. If not, insert them into the sealing
grooves of these parts.

1.

Insert the filter insert into the filter holder
and press it into place.

2.

Insert the worm gear into the housing.

3.

Insert the filter holder into the housing.
Lug on the filter holder must be situated
in the recess on the housing.
