 23

en

Base unit

Base unit

Preparation

W

Risk of injury!

Do not insert the mains plug until all
preparations for working with the appliance
are complete and the required attachments
are assembled correctly and connected to
the base unit.

■

Place the base unit on a stable and level
work surface.

■

Pull the mains cable out of the cable
storage compartment to the required
length.

The base unit is now prepared.

Base attachment

The base attachment can be used for the
following   applications:

Meat mincer

For chopping up raw or cooked food. Select
the appropriate perforated disc depending
on the type and consistency of the food to
be processed.

X

 “Tips” see page 28

Sausage filler

For filling artificial and natural casings with
sausage meat. For producing meat rolls.

Note:

 Other applications are possible

using the base attachment and appropriate
accessories available from Customer
Service.

Caution!

When assembling the different individual
parts, make sure that the notched markings
on the inserts match up with the relevant
one on the housing.

Preparation for meat mincer

W

Risk of injury!

Do not reach into the sharp knife.

Caution!

Always only use one perforated disc.

X

Fig.

D

1.

Insert the worm gear with the agitator
paddle at the front in the housing.

2.

First fit the knife and then the required
perforated disc onto the  worm gear.

3.

Fit the threaded ring onto the housing
and screw tight in a clockwise direction
without using force.

The meat mincer is now prepared.

Preparation for sausage filler

X

Fig.

E

1.

Insert the worm gear with the agitator
paddle at the front in the housing.

2.

First fit the bearing ring onto the worm
gear and then the sausage nozzle into
the housing.

3.

Fit the threaded ring onto the housing
and screw tight in a clockwise direction
without using force.

The sausage filler is now prepared.

Use

Note:

The food is processed in different

ways depending on the application.

X

 “Recipes” see page 28

The following example describes use of
the base attachment as a meat mincer:

W

Risk of injury!

–

Do not reach into the feed chute with
your hands.

–

Only use the pusher when adding more
food.

Caution!

–

Do not process bones, gristle, sinews or
other solid components.

–

Do not process frozen meat.

–

Do not apply great force with the pusher.

X

Fig.

F

1.

Fit the prepared attachment onto the drive
of the base unit, holding it at an angle.

2.

Turn the attachment anticlockwise until
you hear it click into position.

3.

Fit the filling tray and insert the pusher
in the feed chute.

4.

Prepare your food. Chop up large parts
beforehand so they fit into the feed
chute without having to press them in.

■

Place a suitable container under the
attachment. Add the prepared food to
the filling tray.

5.

Connect the mains plug. Switch on the
appliance.
