Specifications

Specifications

CPU

Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with

Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with

Radeon™ Graphics Desktop Processors for Socket AM4

Chipset

AMD®

X570 Chipset

Memory

∙

4x DDR4 memory slots, support up to 128GB*

▪

3rd Gen AMD Ryzen™ Processors support DDR4 1866/

2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by

JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466

/3600/ 3733 /3866 /4000 /4133 /4266 /4400 /4533 /4600

Mhz by A-XMP OC MODE

▪

2nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen

AMD Ryzen™ with Radeon™ Vega Graphics Processors

support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/

3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000

/3066 /3200 /3466 /3600 Mhz by A-XMP OC MODE

∙

Dual channel memory architecture

∙

Supports non-ECC UDIMM memory

∙

Supports ECC UDIMM memory (non-ECC mode)

∙

Supports un-buffered memory

* Please refer www.msi.com for more information on compatible memory.

Expansion Slots

∙

2x PCIe 4.0/ 3.0 x16 slots (PCI_E1, PCI_E3)

▪

3rd Gen AMD Ryzen™ support PCIe 4.0 x16/x0, x8/x8

modes

▪

2nd Gen AMD Ryzen™ support PCIe 3.0 x16/x0, x8/x8

modes

▪

Ryzen™ with Radeon™ Vega Graphics and 2nd Gen

AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0

x8 mode*

∙

1x PCIe 4.0/ 3.0 x16 slot (PCI_E5, supports x4 mode)

∙

2x PCIe 4.0/ 3.0 x1 slots**

* PCI_E3 slot is only available for 2nd and 3rd Gen AMD Ryzen™ processors.
** The PCIe x1 slots can not be used simultaneously. PCI_E2 will be unavailable

when installing the PCIe card in PCI_E4 slot.
***The speeds may vary for different devices

Continued on next page
