PREPARATIONS

11

 En

Eng

lish

PREP

ARA

TION

The receiver is equipped with the iPod dock on the top
panel where you can station your iPod and control
playback of your iPod using the supplied remote control.
Use this receiver with iPod dock adapter (supplied with
your iPod or commercially available) appropriate for your
iPod. If you use this receiver without using an appropriate
iPod dock adapter, loose connection may result.

y

When the receiver is turned on or in standby mode, connect the
iPod during the playback. The receiver automatically starts
playback of iPod (for the fifth or later generation of iPod, iPod
touch, iPod Classic, or iPod nano).

Notes

• Only iPod (Click and Wheel), iPod nano, iPod Classic, iPod

mini and iPod touch are supported.

• Do not connect any iPod accessories (such as headphones, a

wired remote control, or an FM transmitter) to your iPod when
it is stationed in the iPod dock.

• Unless your iPod is firmly stationed in the iPod dock, audio

signals may not be output properly.

• Once the connection between your iPod and the receiver is

complete and the receiver is set to iPod mode (

☞

p.6),

“CONNECTED” appears on the front panel display. If the
connection between your iPod and the receiver fails, a status
message appears on the front panel display. For a complete list
of connection status message, see the iPod section in
“TROUBLESHOOTING” (

☞

p.43).

• When your iPod is stationed in the iPod dock of the receiver,

your iPod can be charged automatically even when the receiver
is in standby mode.

• You can disconnect the iPod during the playback.

This DVD player has a USB port and can access MP3,
WMA, MPEG-4 AAC, or JPEG files saved on your USB
device. Connect your USB device to the USB port on the
front panel of the DVD player.

■

Supported USB devices

This DVD player supports USB mass storage class
devices (e.g., flash memories, card readers or portable
audio players) using FAT16 or FAT32 format.

Notes

• Some devices may not work properly even if they meet the

requirements.

• Do not connect devices other than the USB mass storage class

devices.

• When you insert two or more memory cards at the same time

using card readers, etc., only one of the memory cards is
recognized.

• Yamaha and suppliers accept no liability for the loss of data

saved on the USB devices connected to the receiver. As a
precaution, it is recommended that the files are made backup
copies.

• Playability of and power supply to all kind of USB devices are

not guaranteed.

• When your USB device is connected to the USB port, your

USB device can be charged automatically even when the DVD
player is in standby mode. Some USB devices cannot be
charged in standby mode.

• You can disconnect the USB device during the playback.

Connecting an iPod™

iPod

INPUT

PHONES

BASS

-

+

-

+

L

R

TREBLE

BALANCE

PRESET

PURE DIRECT

VOLUME

MIN

MAX

Receiver

iPod

iPod dock adapter

Connecting USB devices

USB

DVD player

USB device
