Table 1. LED descriptions
Description
LED
Off. No power is supplied to the access point.
Solid green. Power is supplied to the access point and the access point is ready.
Solid amber. During startup, the Power LED lights solid amber. If after five minutes the amber
light remains on, a boot error occurred.
Blinking amber fast, temporarily. The access point is upgrading firmware.
Blinking amber slowly, continuously. The access point did not receive an IP address from a
DHCP server.
Power LED
If the serial number begins with 4W8 or
4W9:
If the serial number begins with 5B4 or 5B5:
Insight LED
Off. The access point functions either in
standalone mode or in Insight mode but is not
connected to the Insight cloud-based
management platform.
Solid green. The access point functions in
Insight mode and is connected to the Insight
cloud-based management platform.
Off. The access point functions either in
standalone mode or in Insight mode but is not
connected to the Insight cloud-based
management platform.
Solid blue. The access point functions in
Insight mode and is connected to the Insight
cloud-based management platform.
Off. Either no powered-on Ethernet device is connected to the WAN PoE port, or, if a
powered-on Ethernet device is connected, no Ethernet link is detected.
Solid amber. A 10 or 100 Mbps Ethernet link is detected on the WAN PoE port.
Blinking amber. 10 or 100 Mbps traffic activity is detected on the WAN PoE port.
Solid green. A 1000 Mbps Ethernet link is detected on the WAN PoE port.
Blinking green. 1000 Mbps traffic activity is detected on the WAN PoE port.
WAN PoE LED
Off. Either no Ethernet device is connected to the LAN port or no Ethernet link is detected.
Solid amber. A 10 or 100 Mbps Ethernet link is detected on the LAN port.
Blinking amber. 10 or 100 Mbps traffic activity is detected on the LAN port.
Solid green. A 1000 Mbps Ethernet link is detected on the LAN port.
Blinking green. 1000 Mbps traffic activity is detected on the LAN port.
LAN LED
Off. The 2.4 GHz WiFi radio is off.
Solid green. The 2.4 GHz WiFi radio is on.
Solid blue. One or more WLAN clients are connected to the 2.4 GHz WiFi radio.
Blinking blue. Traffic is detected on the 2.4 GHz WiFi radio.
2.4G WLAN LED
Off. The 5 GHz WiFi radio is off.
Solid green. The 5 GHz WiFi radio is on.
Solid blue. One or more WLAN clients are connected to the 5 GHz WiFi radio.
Blinking blue. Traffic is detected on the 5 GHz WiFi radio.
5G WLAN LED
Note: For information about troubleshooting with the LEDs, see Troubleshoot with the
LEDs on page 232.
User Manual
16
Hardware Overview of the
Access Point
Insight Managed Smart Cloud Wireless Access Point WAC510 User Manual
