15

English

B560 Pro4

2.3  Installing Memory Modules (DIMM)

This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots,
and supports Dual Channel Memory Technology.

Dual Channel Memory Configuration

The DIMM only fits in one correct orientation. It will cause permanent damage to
the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.

Priority

DDR4_A1

DDR4_A2

DDR4_B1

DDR4_B2

1

Populated

Populated

2

Populated

Populated

Populated

Populated

1.  For dual channel configuration, you always need to install identical (the same

brand, speed, size and chip-type) DDR4 DIMM pairs.

2.  It is unable to activate Dual Channel Memory Technology with only one or three

memory module installed.

3.  It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4

slot; otherwise, this motherboard and DIMM may be damaged.
