DGS-1210 Series Ethernet Managed Switch CLI Reference Guide

355

48

IP-MAC-PORT BINDING COMMANDS

The

IP network layer uses a four-byte address. The Ethernet link layer uses a six-byte MAC address. Binding

these two address types together allows the transmission of data between the layers. The primary purpose of IP-

MAC-port binding is to restrict the access to a switch to a number of authorized users. Only the authorized client

can access the Switch’s port by checking the pair of IP-MAC addresses with the pre-configured database. If an

unauthorized user tries to access an IP-MAC-port binding enabled port, the system will block the access by

dropping its packet. The maximum number of IP-MAC-port binding entries is dependant on chip capability (e.g.

the ARP table size) and storage size of the device. For the Switch, the maximum value for the IP-MAC-port

binding ARP mode is 500. The creation of authorized users can be manually configured by CLI or Web. The

function is port-based, meaning a user can enable or disable the function on the individual port.

The IP-MAC-Port Binding commands in the Command Line Interface (CLI) are listed (along with the

appropriate parameters) in the following table:


Command

Parameter

create address_binding

ip_mac

[ipaddress  <ipaddr> | ipv6address <ipv6addr>] mac_address <macaddr> ports

[<portlist> | all]

config address_binding

ip_mac ports

[<portlist> | all] {state [disable | enable] | ip_inspection [disable | enable] |

arp_inspection [loose | strict] | allow_zeroip [enable | disable] | forward_dhcppkt

[enable | disable] | protocol [ipv4 | ipv6 | all]}

config address_binding

auto_scan

from_ip <ipaddr> to_ip <ipaddr>

config address_binding

auto_scan ipv6address  from_ip <ipv6addr> to_ip <ipv6addr>

delete address_binding

[ip_mac [ipaddress <ipaddr> | ipv6address <ipv6addr> | mac_address

<macaddr> | all] | blocked [all | vlan_name <string 32> mac_address <macaddr>

port <port 1-28>]]

show address_binding  {[ip_mac [all | {ipaddress <ipaddr> | ipv6address <ipv6addr> | mac_address

<macaddr>}] }

show address_binding

auto_scan list

enable

address_binding

dhcp_snoop

ports {<portlist> | all} [vlan <vidlist>] [{ipv6 | all}]

disable

address_binding

dhcp_snoop

ports {<portlist> | all} [{ipv6 | all}]

config address_binding

dhcp_snoop

{max_entry ports [<portlist> | all] limit [<int 1-10> | no_limit] {IPv6}} |

{flush_on_port_down ports <portlist> | all] [enable | disable]}

show address_binding

dhcp_snoop

[binding_entry | flust_status | max_entry | vlan_list] ports <portlist>

Each command is listed in detail, as follows:


create address_binding ip_mac

Purpose

Used to create an IP-MAC-port binding entry.
