GB

Laser measuring tool

0530

INTRODUCTION

•  This tool is intended for measuring distances indoors as

well as outdoors by means of laser beam projection

•  When used properly, this tool easily and accurately

measures length, surface and volume

•

Carefully read this instruction manual and pay
special attention to the safety instructions and
warnings; failure to follow these may result in
serious (eye) injury

1

•  Before using the tool for the first time, paste the

supplied sticker in your national language over the
German text of warning label P

3

•  Save this instruction manual for future reference

TECHNICAL SPECIFICATIONS

Measuring method

optic/laser

Measuring range

0.2 - 20 m

1

)

Measuring accuracy (typical)  +/- 3.0 mm

2

)

Measuring duration (typical)

< 0.5 sec.

Lowest indication unit

1 mm

Operating temperature

-10°C to 50°C

Storage temperature

-20ºC to 70°C

Relative humidity (max.)

90%

Laser class

2

Laser type

635 nm

Maximum power output

< 1 mW

Laser beam diameter
(at approx. 20°C)
- at 10 m distance

6 mm

- at 20 m distance

16 mm

Batteries (included)

4 x AAA (LR03) 1.5V

Rechargeable batteries

4 x AAA (KR03) 1.2V

Automatic switch-off
- laser

 after approx. 20 sec. of
non-measurement

- measuring tool

 after approx. 5 min. of
inactivity

Weight

0,18 kg

1)  The measuring range increases depending on how well

the laser light is reflected from the target surface and
how bright the laser point is in relation to the ambient
light intensity

2)  The measuring accuracy deviates +0,06% at

unfavorable conditions (e.g. at intense sunlight)

TOOL ELEMENTS

3

A

  Reception lens

B

  Laser beam opening

C

  LCD display

D

  On/off button

E

  Metre/feet conversion button

F

  Length and continuous measurement mode

G

  Surface measurement mode

H

  Volume measurement mode

J

  Clearing button (“C”)

K

  Memory add button (“M+”)

L

  Memory subtract button (“M-”)

M

 Memory retrieve button (“M=”)

N

  Measuring button (“GO”)

P

  Warning label

Q

  Battery compartment cover

SAFETY

•

Do not look into the laser beam (laser radiation)

2

•  Do not point the laser beam at persons or animals

•  Do not place the tool in a position that may cause

anyone to look into the laser beam intentionally or
unintentionally

•  Do not use any magnifying optical tools (such as

magnifying glasses, telescopes, or binoculars) to view
the laser beam

•  Do not remove or damage the warning label on the tool
•  Do not operate the tool in the presence of flammable

liquids, gases or dust

•  Do not operate the tool with children around
•  This tool should not be used by people under the age of

16 years

•  Do not use the tool for any purpose other than those

mentioned in this instruction manual

USE

•  Mounting of batteries

4

!  ensure that the tool is switched off

-  use exclusively alkaline-manganese or rechargeable

batteries

-  turn tool upside down
-  remove cover Q
-  insert 4 x 1,5V battery (pay attention to correct

polarisation)

-  mount cover Q
-  when battery level is low, symbol

5

 will appear in

display

-  when symbol

5

 appears in the display for the first

time, then at least 100 measurements are still
possible

-  replace the batteries when symbol

5

 starts flashing

(measuring no longer possible)

-  always replace the complete set of batteries
-  always remove the batteries from the tool, if the tool

will not be used for a long period

•  On/off

-  switch on the tool by either pressing “on/off” or “GO”

(the laser beam is not switched on yet)

-  switch off the tool by pressing “on/off”
-  the tool automatically switches off after 5 minutes of

inactivity

•  Metre/feet conversion

-  measurements are in metres/centimetres by default
-  press button E

3

 for converting metres/centimetres

into feet/inches

•  Operating the tool

6

-  switch on the tool (symbol

7

 appears in display

indicating that the tool is already in the length
measurement mode)

-  select other measurement mode (surface/volume), if

desired
