Controls
a
Power Switch [
A
,
M
,
P
, OFF]
b
Recording Start/Stop Button
c
Lock Button
d
Snapshot Button [SNAPSHOT]
e
Power Zoom Switch [T/W]
f
Information Button [INFO]
g
Index Button [INDEX]
h
Playback Mode Switch [VIDEO/MEMORY]
i
Stop Button [
8
]
j
Rewind Button [
3
]
k
Play/Pause Button [
4
·
9
]
l
Fast-Forward Button [
5
]
m
Thumbnail Storing Button [NAVI STORE]
n
Program AE Button [P.AE]
o
Shutter Speed/Iris Control Button [S/A]
p
Manual White Balance button
[WHITE BALANCE]
q
•Menu Wheel [MENU]
•Speaker/Headphone Volume Control
[VOLUME +, –]
r
i.LINK Output Select Switch [DV/MPEG2]
s
Blank Search Button [BLANK SEARCH]
t
Navigation Button [NAVI]
u
Wipe or Fader Effect Button [FADE/WIPE]
v
Special Effects Button [EFFECT]
w
Manual Zoom Ring
x
Cassette Open/Eject Switch
[OPEN/EJECT]
y
Recording Mode Switch
[MEMORY/HI-RES/PS50/DV]
z
Manual Focus Ring
j
Backlight Compensation Button [BACK LIGHT]
k
Manual Focus Button [FOCUS]
l
Exposure Adjustment Wheel
[EXPOSURE]
;
Monitor Opening Button
[PUSH OPEN]
z
Battery Release Switch [BATTERY]
x
Dioptre Adjustment Control
Connectors
The connectors are located beneath the covers.
g
Microphone connector [MIC]
Open the connector cover, and attach the
optional microphone.
h
S/AV connector
i
Headphone Connector [ ]
No sound is output from the speaker when
headphones are connected to this connector.
j
USB (Universal Serial Bus) Connector
k
DC Input Connector [DC]
l
Digital Video Connector
[i.LINK IN/OUT] (i.Link*)
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
m
Component Video Connectors [Y/Pb/Pr]
Indicators
Y
Power Lamp
Z
Tally Lamp
Other Parts
q
Battery Pack Mount
r
Shoulder Strap Eyelet
s
Grip Strap
t
•Cassette Holder Cover
•Rotating Grip
u
Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
v
Lens Hood
w
Remote Sensor
x
LCD Monitor
y
Speaker
z
Stereo Microphone
Shoe
Attach the provided Handle, optional Stereo
Microphone or Video Light. Make sure to turn off
the power of the camcorder and the video light
or microphone before attaching and removing
them.
Viewfinder
Card Cover [MEMORY CARD]
Stud Hole
Tripod Mounting Socket
Viewfinder Cleaning Hatch
