Noise/Vibration Information

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, until
19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards: EN 60745-1,
EN 60745-2-3.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 27.08.2015

Assembly



Before any work on the machine itself, pull the mains
plug.

Inserting/Replacing Diamond Cup Wheels
(see figure A)

Approved Grinding Tools

All diamond cup wheels mentioned in these operating instruc-
tions can be used.

Observe the dimensions of the diamond cup wheels. The
mounting hole diameter must fit the mounting flange without
play. The mounting hole of the diamond cup wheel may not be
increased. Do not use reducers or adapters.

The permissible speed [rpm] or the circumferential speed
[m/s] of the diamond cup wheels used must at least match
the values given in the table.

Therefore, observe the permissible

rotational/circumferen-

tial speed

 on the label of the diamond cup wheel.

Inserting Diamond Cup Wheels

Select a suitable diamond cup wheel for the material to be
worked. Please also observe the material information on the
packaging of the diamond cup wheel.

Clean the grinder spindle

13

 and all parts to be mounted.

Place the mounting flange

14

 on the grinder spindle

13

 so

that the centring collar faces away from the machine. The
mounting flange must engage on the flats of the grinder spin-
dle (anti-twist protection).

Sound emission values determined according
to EN 60745-2-3.

GBR 15 CAG

GBR 15 CA

3 601 G76 0..

3 601 G76 0..

Typically the A-weighted noise levels of the
product are
Sound pressure level
Sound power level
Uncertainty K

Wear hearing protection!

dB(A)
dB(A)

dB

92

103

3

92

103

3

Vibration total values a

h

 (triax vector sum) and

uncertainty K determined according to
EN 60745-2-3:

a

h

K

m/s

2

m/s

2

4.5
1.5

5.5
1.5

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9

max.

[mm]

[mm]

D

d

[min

-1

]

[m/s]

125

22.2

11 000

80

D

d
