English

Z390 Extreme4

25

ATX 12V Power
Connector
(8-pin ATX12V1)
(see p.1, No. 1)

This motherboard
provides an 8-pin ATX
12V power connector. To
use a 4-pin ATX power
supply, please plug it along
Pin 1 and Pin 5.

ATX 12V Power
Connector
(4-pin ATX12V2)
(see p.1, No. 2)

Please connect an ATX
12V power supply to this
connector.
*The power supply plug
fits into this connector in
only one orientation.

Thunderbolt AIC
Connectors
(5-pin TB1)
(see p.1, No. 24)

Please connect a Thunderbolt™
add-in card (AIC) to the
Thunderbolt AIC connector via
the GPIO cable.
*Please install the Thunderbolt™
AIC card to PCIE6 (default
slot).

Serial Port Header
(9-pin COM1)
(see p.1, No. 21)

This COM1 header
supports a serial port
module.

TPM Header
(17-pin TPMS1)
(see p.1,  No. 22)

This connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certificates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.

4                            1

8                            5

1

C C T S # 1

R R T S # 1

D D S R # 1

D D T R # 1

R R X D 1

G N D

T T X D 1

D D C D # 1

1

R R I # 1

1

G

N

D

SM

B_

D

A

TA

_M

A

IN

LA

D

2

LA

D

1

G

N

D

S_

PW

RD

W

N

#

SE

RI

RQ

#

G

N

D

P

C

IC

LK

P

C

IR

ST

#

LA

D

3

+

3

V

LA

D

0

+

3V

S

B

G

N

D

FR

A

M

E

SM

B_

C

LK

_M

A

IN
