English

Z390 Extreme4

9

* M2_1, SATA3_0 and SATA3_1 share lanes. If either one of
them is in use, the others will be disabled.
* M2_2, SATA3_4 and SATA3_5 share lanes. If either one of
them is in use, the others will be disabled.

•

1 x Ultra M.2 Socket (M2_1), supports M Key type
2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2
PCI Express module up to Gen3 x4 (32 Gb/s)**

•

1 x Ultra M.2 Socket (M2_2), supports M Key type
2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module
and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**

** Supports Intel® Optane

TM

 Technology

** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit

Connector

•

1 x COM Port Header

•

1 x TPM Header

•

1 x Power LED and Speaker Header

•

2 x RGB LED Headers

* Support in total up to 12V/3A, 36W LED Strip

•

1 x Addressable LED Header

* Supports in total up to 5V/3A, 15W LED Strip

•

1 x CPU Fan Connector (4-pin)

* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.

•

1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)

* The CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.

•

3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)

* The Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP and
CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use.

•

1 x 24 pin ATX Power Connector (Hi-Density Power
Connector)

•

1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
