Adjusting the Cutting Angle

f

When adjusting the cutting angle, never ac-
tuate the On/Off switch 20.

Danger of injury

if the machine should accidentally start.

Adjusting Horizontal Mitre Angles

The horizontal mitre angle can be set in the
range from 47 °  (left side) to 47 °  (right side).
– Loosen the locking knob

9

 in case it is tight-

ened.

– Turn the saw table

8

 left or right by the lock-

ing knob until the angle indicator

12

 indi-

cates the requested mitre angle.

– Tighten the locking knob

9

 again.

For quick and precise setting of often used mi-
tre angles,

 the saw table

8

 engages at the de-

tents of the following standard angles:
– 45 ° /  – 30 ° /– 22.5 ° /  – 15 ° /
0 ° / 15 ° / 22.5 ° / 30 ° / 45 °

Adjusting Vertical Bevel Angles
 (see figure I)

The vertical bevel angle can be set in the range
from 0 °  to 45 ° .
– Loosen the clamping lever

17

.

– Tilt the tool arm by the handle

1

 until the an-

gle indicator

39

 indicates the desired bevel

angle.

– Hold the tool arm in this position and retight-

en the clamping lever

17

.

For quick and precise setting of the standard
angles 0 °  und 45 ° ,

 end stops are provided on

the housing.
– Loosen the clamping lever

17

.

– For this, tilt the tool arm by the handle

1

 to

the stop toward the right (0 ° ) or to the stop
toward the left (45 ° ).

– Retighten the clamping lever

17

 again.

Starting Operation

f

Observe correct mains voltage! The voltage
of the power source must agree with the
voltage specified on the nameplate of the
machine. Power tools marked with 230 V
can also be operated with 220 V.

Switching On (see figure J)

– To

start

 the machine, press the On/Off

switch

20

 and keep it pressed.

Note:

For safety reasons, the On/Off switch

20

cannot be locked; it must remain pressed during
the entire operation.
The tool arm can only be guided downward
when pressing lever

3

.

– For

sawing

, you must additionally press lever

3

 in addition to actuating the On/Off switch

20

.

Switching Off

– To

switch off

 the machine, release the

On/Off switch

20

.

Working Advice

General Sawing Instructions

f

Always firmly tighten locking knob 9 and
clamping lever 17 before sawing.

Otherwise

the saw blade could become jammed in the
workpiece.

f

For all cuts, it must first be ensured that the
saw blade at no time can come in contact
with the fence, screw clamps or other ma-
chine parts. Remove possibly mounted aux-
iliary stops or adjust them accordingly.

Protect the saw blade against impact and shock.
Do not subject the saw blade to lateral pressure.
Do not saw warped/bent workpieces. The work-
piece must always have a straight edge to face
against the fence.
Long workpieces must be underlaid or support-
ed at their free end.

Marking the Cutting Line (see figure K)

A laser beam indicates the cutting line of the
saw blade. This allows for exact positioning of
the workpiece for sawing, without having to
open the retracting blade guard.
– For this, switch the laser beam on with the

switch

21

.

– Align the cutting mark on your workpiece

with reference to the right-hand edge of the
laser line.
