32

 | English

1 609 929 W43 | (22/7/10)

Bosch Power Tools

Assembly

f

Avoid unintentional starting of the ma-
chine. During assembly and for all work on
the machine, the power plug must not be
connected to the mains supply.

Delivery Scope

Please also observe the represen-
tation of the delivery scope at the
beginning of the operating instruc-
tions.

Before starting the operation of the machine for
the first time, check if all parts listed below have
been supplied:
– Sliding mitre saw with premounted saw

blade

– Dust bag

19

– Saw-table extension

14

 (2x)

– Material clamp

16

– Allen key

25

– Batteries (2x, size LR03, 1.5 V)

Note:

Check the power tool for possible dam-

age.
Before further use of the machine, check that all
protective devices are fully functional. Any light-
ly damaged parts must be carefully checked to
ensure flawless operation of the tool. All parts
must be properly mounted and all conditions
fulfilled that ensure faultless operation.
Damaged protective devices and parts must be
immediately replaced by an authorised service
centre.

Additionally required tools (not in delivery
scope):

– Phillips screwdriver

Mounting Individual Components

– Carefully remove all parts included in the de-

livery from their packaging.

– Remove all packaging material from the ma-

chine and the accessories provided.

– For easier working when mounting the sup-

plied product features, please observe that
the machine is in the transport position.

Inserting the Batteries (see figure A)

– Open the battery compartment

31

.

– Insert the batteries provided according to

the specified polarity.

– Close the battery compartment.

Mounting Saw-table Extensions (see figure B)

The saw-table extensions

14

 can be positioned

on the left, right or front of the saw table base.
The flexible plug-in system enables a variety of
extension possibilities (see figure H).
– Insert the saw-table extension

14

 into the

openings

28

 of the saw-table base or into the

openings

32

 of the second saw-table exten-

sion.

Stationary or Flexible Mounting

f

To ensure safe handling, the machine must
be mounted on a level and stable surface
(e. g., workbench) prior to using.

Mounting to a Working Surface (see figure D1)

– Screw the tilt protector

10

 in or out until the

machine is positioned level on the working
surface.

– Fasten the power tool with suitable screw

fasteners to the working surface. The holes

7

serve for this purpose.

Mounting to a Bosch Saw Stand
(see figure D2)

With the height-adjustable legs, Bosch saw
stands (e.g. PTA 2400) provide firm support for
the power tool on any surface. The workpiece
supports of the saw stand are used for underlay-
ing long workpieces.

Note:

To support long workpieces in this case,

only use the workpiece supports of the saw
stand and not the power tool’s saw-table exten-
sions

14

.

f

Read all safety warnings and instructions
included with the worktable.

Failure of ob-

serving safety warnings and instructions can
lead to electrical shock, fire and/or cause se-
rious injuries.
