Mounting the Saw Blade

If required, clean all parts to be mounted prior
to assembly.
– Press lever

3

, swing back the retracting

blade guard

5

 to the stop and hold it in this

position.

– Place the new saw blade onto the interior

clamping flange

35

.

f

When mounting the saw blade, pay atten-
tion that the cutting direction of the teeth
(arrow direction on the saw blade) corre-
sponds with the direction of the arrow on
the blade guard!

– Slowly guide the retracting blade guard

downward again.

– Place on the clamping flange

34

 and the

screw

33

.

Press the spindle lock

30

 until it engages and

tighten the screw turning in anticlockwise di-
rection.

Operation

f

Before any work on the machine itself, pull
the mains plug.

Transport Safety (see figure F)

The transport safety-lock

29

 enables easier han-

dling of the machine when transporting to vari-
ous working locations.

Releasing the Machine (Working Position)

– Push the tool arm by the handle

1

 down a lit-

tle in order to relieve the transport safety-
lock

29

.

– Pull the transport safety-lock

29

 completely

outward.

– Guide the tool arm slowly upward.

Securing the Machine (Transport Position)

– Loosen the locking screw

26

 if tightened.

Pull the tool arm completely to the front and
tighten the locking screw again.

– Screw the depth stop

18

 completely to the

top. (see “Adjusting the Depth Stop”,
page 36)

– To lock the saw table

8

, tighten the locking

knob

9

.

– Press lever

3

 and at the same time, swing the

tool arm by handle

1

 toward the rear until the

transport safety-lock

29

 can be pushed com-

pletely inward.

The tool arm is now securely locked for trans-
port.

Clamping the Workpiece (see figure G)

To ensure optimum working safety, the work-
piece must always be firmly clamped.
Do not saw workpieces that are too small to
clamp.
– Press the workpiece firmly against the

fence

15

.

– Insert the material clamp

16

 provided into

one of the holes

23

 intended for it.

– Loosen the wing bolt

37

 and adapt the mate-

rial clamp to the workpiece. Tighten the wing
bolt again.

– Firmly clamp the workpiece by turning the

threaded rod

38

 in clockwise direction.

Loosening the Workpiece

– To release the material clamp, turn the

threaded rod

38

 in anticlockwise direction.

Extending the Saw Table (see figure H)

Long workpieces must be underlaid or support-
ed at their free end.
The flexible saw-table extension plug-in system

14

 enables a variety of extension possibilities.

– Insert the saw-table extension

14

 into the

openings

28

 of the saw-table base or into the

openings

32

 of the second saw-table exten-

sion.
