41

Slide device

42

Casing stop for depth stop

43

Screws for insert plate

Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.

Technical Data

Noise/Vibration Information

Measured sound values determined according
to EN 61029.
Typically the A-weighted noise levels of the
product are: Sound pressure level 94 dB(A);
Sound power level 107 dB(A). Uncertainty
K = 3 dB.

Wear hearing protection!

Vibration total values (triax vector sum) deter-
mined according to EN 61029:
Vibration emission value a

h

< 2.5 m/s

2

, Uncer-

tainty K = 1.5 m/s

2

.

The vibration emission level given in this infor-
mation sheet has been measured in accordance
with a standardised test given in EN 61029 and
may be used to compare one tool with another.
It may be used for a preliminary assessment of
exposure.
The declared vibration emission level repre-
sents the main applications of the tool. However
if the tool is used for different applications, with
different accessories or poorly maintained, the
vibration emission may differ. This may signifi-
cantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibra-
tion should also take into account the times
when the tool is switched off or when it is run-
ning but not actually doing the job. This may sig-
nificantly reduce the exposure level over the to-
tal working period.
Identify additional safety measures to protect
the operator from the effects of vibration such
as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.

Declaration of Conformity

We declare under our sole responsibility that
the product described under “Technical Data” is
in conformity with the following standards or
standardization documents: EN 61029,
EN 60825-1 according to the provisions of the
directives 2004/108/EC, 2006/42/EC.
Technical file at:
Robert Bosch GmbH, Dept. PT/ESC,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

Leinfelden, 22.07.2010

Sliding Mitre Saw

PCM 7 S

Article number

3 603 M01 3..

Rated power input

W

1200

No-load speed

min

-1

4800

Laser type

nm

mW

650

< 1

Laser class

2

Weight according to
EPTA-Procedure
01/2003

kg

11.8

Protection class

/

II

Permissible workpiece dimensions (maximal/minimal)
see page 36.

The values given are valid for a nominal voltage [U] of
230 V. For different voltages and models for specific
countries, these values can vary.

Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.

Dimension of suitable saw blades

Saw blade diameter

mm

190

Blade thickness

mm

1.4 – 2.5

Mounting hole diameter

mm

30

Dr. Egbert Schneider
Senior Vice President
Engineering

Dr. Eckerhard Strötgen
Head of Product
Certification
