30

 | English

1 609 929 W43 | (22/7/10)

Bosch Power Tools

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

Intended Use

The power tool is intended as a stationary ma-
chine for making straight lengthways and cross-
ways cuts in wood. In this, mitre angles from
– 47 °  to +47 °  as well as bevel angles from 0 °  to
45 °  are possible.
The capacity of the power tool is designed for
sawing hardwood and softwood.
The power tool is not suitable for cutting alumin-
ium or other non-ferrous metals or alloys.

Product Features

The numbering of the components shown refers
to the representation of the power tool on the
graphic pages.

1

Handle

2

Laser warning label

3

Lever for releasing the tool arm

4

Blade guard

5

Retracting blade guard

6

Roller

7

Mounting holes

8

Saw table

9

Locking knob for various mitre angles
(horizontal)

10

Tilt protector

11

Insert plate

12

Angle indicator (horizontal)

13

Scale for mitre angle (horizontal)

14

Saw-Table extension

15

Fence

16

Material clamp

17

Clamping lever for various bevel angles
(vertical)

18

Depth stop

19

Dust bag

20

On/Off switch

21

Laser switch (for marking of cutting line)

22

Sawdust ejector

23

Drill holes for material clamp

24

Transport handle

25

Allen key (size 6 mm)

26

Locking screw for slide device

27

Recessed grips

28

Opening for saw-table extension
(on saw table base)

29

Transport safety-lock

30

Spindle lock

31

Battery compartment

32

Opening for saw-table extension
(on the second saw-table extension)

33

Allen screw (size 6 mm) for mounting of saw
blade

34

Clamping flange

35

Interior clamping flange

36

Saw blade

37

Wing bolt

38

Threaded rod

39

Angle indicator (vertical)

40

Scale for bevel angle (vertical)

Only for EC countries:

Do not dispose of power tools into household waste!
According the European Guideline 2002/96/EC for Waste Electrical and
Electronic Equipment and its implementation into national right, power
tools that are no longer usable must be collected separately and dis-
posed of in an environmentally correct manner.

Symbol

Meaning
