RG68XX / RG69XX / RG72XX / RG73XX / RG82XX
Error

Indicator Light

Error

Designations

Error Forms

Solutions

The red indicator light

blinks twice and beeps

Failure of the left wheel

The left wheel does not

turn and is overloaded.

Please confirm that the

device's left wheel is not

covered.

The red indicator light

blinks three times and

beeps

Failure of the right wheel

The right wheel does

not turn and is over-

loaded

Please confirm that the

device's right wheel is not

covered.

The red indicator light

blinks five times and

beeps

Failure of the front wheel

The front wheel is blocked

and no longer turns.

Please confirm that the

small wheels of the front

wheel are not covered.

The red indicator light

blinks six times and

beeps

Failure of the ground

inspection

There is a problem with

the ground inspection.

Please confirm that the sen-

sor window at the bottom

of the device is not unusu-

ally concealed.

The red indicator light

blinks seven times and

beeps

Low current or battery

The battery power sup-

ply was extremely low

(but not at the recharge

voltage critical point).

Please replace the device

on the docking station to

recharge it.

The red indicator light

blinks eight times and

beeps

Failure of the front

bumper

The impact switches

on the front left and

right shells cannot be

restored.

Please check whether or not

the device's stop is normal.

The red indicator light

blinks nine times and

beeps

Failure of the main brush

The wheel of the main

brush is overloaded or

insufficiently charged.

Please confirm that no for-

eign bodies are present on

the device's main brush.

The red indicator light

blinks ten times and

beeps

Failure of the side brush

The side sweeper wheel

is overloaded or insuffi-

ciently charged.

Please confirm that ele-

ments such as hair or fabric

are not wound around the

side brush.

The red indicator light

blinks eleven times and

beeps

Failure of the wall in-

spection

There is a problem with

the wall inspection.

Please confirm that the wall

inspection clear window is

not concealed or obstructed

by hair or fabric.

The red indicator light

blinks twelve times and

beeps

Failure of the fan

The fan only turns with

significant current flow.

Please confirm that the

fan blades are not loose or

jammed by hair or fabric.

The red indicator light

blinks fourteen times

and beeps

Load failure

The device cannot be

supplied with power

or cannot indicate the

charge status.

Please confirm that the

device is connected to the

docking station.

Please keep this user manual.

사용설명서

안전을 위해, 이 기기는 현존하는 모든 표준과 규정을 준수하고 있습니다.

•  본 제품은 가정용으로 제조되었습니다. 이 안전 지침을 주의깊게

읽어 주십시오. 이 지침을 위반하여 제품을 사용한 경우 제조업자는

이에 대해 어떤 책임도 지지 않을 것입니다.

•  본  제품은  전기  기기이므로  정상적인  사용  조건에서  사용해야

합니다.

•  기기를  넘어뜨리거나  떨어뜨린  후  외관상의  손상이  있거나  이상

작동할 경우, 사용하지 마십시오. 이런 경우에는 기기를 열지 말고,

가까운  서비스  센터에  연락하십시오.  안전하게  수리하려면  특수

도구가 필요합니다.

•  수리는  전문가가  정품  부품을  이용하여  해야  합니다.  사용자가

직접  수리하려  할  경우  위험할  수  있습니다.  보증  정품  부품만

사용하십시오(필터, 배터리 등).

•

주의

 [Use only with – designation – charger]

•

주의:

 배터리를 충전하려면, 기기와 함께 제공된 탈착식 전원 장치

(충전기)를 이용하십시오(22쪽).

• 폐기하기 전 배터리를 분리하십시오.

• 배터리를 빼기 전 기기를 꼭 전원에서 분리하십시오.

• 배터리를 안전하게 폐기하십시오.

•  탈착식  전원  장치(충전기)  전선이  손상되었거나  작동하지

않는다면,  제조사에서  제공된  모델  이외의  탈착식  충전  장치(

충전기)는  사용하지  마십시오.  고객  지원에  연락하거나  가까운

서비스 센터를 방문하십시오(유니버설 탈착식 충전 장치(충전기)

사용 시 제품 보증이 적용되지 않습니다).

•  탈착식  충전  장치(충전기)를  분리할  때  전원  코드를  잡아당기지

마십시오.

• 기기 유지 관리나 세척 전 기기 전원을 꼭 끄십시오.

• 진공청소기 전원을 끄지 않은 채 회전 부품에 손을 대지 마십시오.

•  물이나 액체, 뜨거운 물질, 초미세 입자(석회, 시멘트, 재 등), 크고

날카로운  잔해(유리조각),  유독  제품(용매,  연마재  등),  위험물

(산,  청소용  세척제  등),  가연성  물질(기름  또는  알코올  성분)을

진공청소기로 빨아들이지 마십시오.

   기기를  절대  물에  담그지  마십시오.  기기  위에  물을  흘리지  말고

실외에 보관하지 마십시오.

  처음으로 사용, 청소와 관리할 시, 사용 설명서를 참고해 주십시오.
•

EU 규정에 해당되는 국가 ( 마크):

8세 이상의 어린이 및 제한된

신체적, 감각적, 정신적 능력을 지녔거나 경험이나 지식이 부족한

사람일지라도 감독하는 사람이 있거나 안전하게 기기를 사용하는

KO
