125

Unlock the blockade and disconnect the extension pipes.similarly,

–

disconnect the hose and the nozzle.
Take the water

fi

 lter out of the container.

–

Remove the foam

fi

 lter from the water

fi

 lter and rinse it with running

–

water with the water stream moving from the inner side of the foam.

ATTENTION!!!  Do not wash the

fi

 ltering inserts manually (squeezing) or with

a washing machine.Avoid folding, pulling and deformations.
Having cleaned the foam let it dry either unwrapped or
hanged.

Never dry the foam on heaters, radiators, ovens, etc.

set the three-position switch (

–

1

) to “

1

”,

proceed as in case of steam cleaning the smooth

–

surfaces except for that upon spraying is stopped
and before the liquid is sucked in you should attach
the suction nozzle to the connector.

STEAM CLEANING VERY DIRTY AREAS

Prior to any replacement of the accessories wait until all the components cool
down.
The following mode is recommended to clean joints between tiles, oven windows,
cookers and hoods. It can be also applied to clean kitchen sinks, wash-basins and
sanitary equipment.
The time and intensity of cleaning depends on the amount of dirt.
In order to do this:

attach the connector and the steam spray nozzle on the detergent/steam

–

extension pipe and lock this joint by turning the blockade,
if you have problems with removing dirt install the brush at the nozzle tip.

–

ATTENTION!!!  The brush is hard bristle and may scratch soft surfaces when subject to a direct

contact

WHEN YOU HAVE FINISHED VACUUMING

Switch the vacuum cleaner off by pressing the main switch and remove the plug from the socket.

–

ATTENTION!!!  Wait until the hose, the nozzles, the tubes and the nozzle jets cool down. Then,

disconnect them.

Turn the hose until the

▼

 symbols on the hose and the

–

container are located opposite to each other. Remove the
hose from the slot.
Press the red button in vacuum cleaner base and remove the

–

hose stub.

Remove the dirty water from the container through the slot.

–

Wash the container and the water

fi

 lter thoroughly, repeat this

–

operation a number of times using fresh water each time.
Then, thoroughly wash all vacuum cleaner components used (hose, tubes,

–

accessories).

ATTENTION!!!  Failure to wash these components thoroughly may affect the

fi

 ltering capacity of the inserts and foam and may contribute to

proliferation of bacteria and saprophytes.

Dry all the components.

–

ATTENTION!!!  Never assemble the vacuum cleaner before all components dry.

IInert the water

fi

 lter, set the container in place and close the upper cover.

–
