118

C –

VACUUMING DIRECTLY TO FILTER CHAMBER, WITHOUT A PAPER BAG, WITH OR WITHOUT
A “FIZELINA” FILTERING INSERT

Check if a paper bag is in the

fi

 lter chamber and remove it, if necessary.

–

Check if the upper cover is properly

fi

 xed to the

fi

 lter chamber (clamps

–

1

 and

2

should be locked).To do this proceed according to the description under p.“

A

”.

Release the clamp at the bottom of the

fi

 ltration chamber, insert the FIZELINA

–

(black insert) or do not insert it.

While vacuuming with the FIZELINA insert in place, the dust and dirt stored in
the

fi

 lter chamber above the FIZELINA are wet.

ATTENTION !!! You can use a disposable (quick replacement) or a reusable FIZELINA insert

(cheaper but requires washing or rinsing).

B –  VACUUMING WITH A PAPER BAG AND WITH 1.5l-WATER AS AN ADDITIONAL FILTER

With these

fi

 ltration systems it is possible to operate the vacuum cleaner in one of the following modes:

A –  VACUUMING WITH A PAPER BAG AND WITHOUT A WATER

Press the clamp and lift the upper cover.

–

Take the front container out and remove the

fi

 lter from it.

–

Release the clamps, which

fi

 x the upper cover to the

fi

 ltration

–

chamber, by pressing it with your both thumbs, as shown on
the picture.
Lift the

fi

 lter handle until it reaches the vertical position, pull out

–

the upper cover and open the dust-storage chamber.

The slots, which the paper bag can be attached to, are located
inside the chamber:

Fold the paper bag along the dashed line in the direction

–

indicated by the arr.
Insert it vertically into the slot as indicated by the arrow on the

–

picture. The hole in the paper bag should overlap with the

fi

 lter

inlet.
Bend the cardboard inwards (along the marked line) and lift the

–

fi

 lter handle until it is positioned vertically.

Insert the cover clamps into the rectangular slots, put the handle

–

on the cover and lock it.
Press the upper cover with your thumbs at each clamp (

–

1

 and

2

on the picture), either one by one or concurrently, until you

hear a click.

ATTENTION !!! Both clamps should always be locked!

Proceed as recommended for p.“

A

”.Then, do the following:

Release the clamp at the bottom of the

fi

 ltration chamber (

–

1

).

Insert the white GORETEX

fi

 ltering insert (

2

) and press the

clamps.
Pour 1,5l of water into the front container.The water level should

–

be between the

MIN

 and

MAX

 indications.

ATTENTION !!! Always use the “GORETEX”

fi

 ltering  insert

while vacuuming with a paper bag.
After vacuuming do not leave the paper bag
in the

fi

 ltration chamber if there is water left in

the front container.
