 English |

25

Bosch Power Tools

2 609 140 807 | (21.1.11)

Product Features

The numbering of the product features shown
refers to the illustration of the measuring tool
on the graphic page.

1

Display

2

Measuring button

3

Button for grade measurement/calibration **

4

Button for function mode/basic settings **

5

Minus button

6

Button for result/timer function **

7

Button for measured-value list/storage of
constant **

8

Button for clearing the internal memory/
On/Off **

9

Positioning pin

10

Button for selection of the reference level

11

Plus button

12

Button for length, area and volume measure-
ment

13

Charge socket cover

14

Socket for charge connector

15

Fixture for carrying strap

16

Laser beam outlet

17

Reception lens

18

Serial number

19

1/4" thread

20

Laser warning label

21

Charge connector

22

Battery charger

23

Protective pouch

24

Measuring rail

25

Locking lever for measuring rail

26

Tripod*

27

Laser viewing glasses *

28

Laser target plate *

* The accessories illustrated or described are not in-
cluded as standard delivery.
** Keep button pressed to call up the extended func-
tions.

Display Elements

a

Measured-value lines

b “ERROR”

 indication

c

Result line

d

Digital vial/position of measured-value list
entry

e

Measured-value list indicator

f

Measuring functions

g

Battery charge-control indicator

h

Laser, switched on

i

Measurement reference level

k

Temperature warning

Assembly

Battery Charging

f

Do not use other battery chargers.

The sup-

plied battery charger is designed for the Lith-
ium-Ion battery in your machine.

f

Observe the mains voltage!

The voltage of

the power source must correspond with the
data on the type plate of the battery charger.

Note:

The battery is supplied partially charged.

To ensure full capacity of the battery, complete-
ly charge the battery in the battery charger be-
fore using your power tool for the first time.
The lithium-ion battery can be charged at any
time without reducing its service life. Interrupt-
ing the charging procedure does not damage the
battery.

Length measurement
Area/surface measurement
Volume measurement
Continuous measurement
Indirect height measurement
Double indirect height measurement
Indirect length measurement
Timer function
Wall-surface measurement
Grade measurement

1

1

2

1
